Recessed Area and Closet Installation Instructions
This dryer may be installed in a recessed area or closet.
For recessed area and closet installations, minimum clearances
can be found on the warning label on the rear of the dryer.
The installation spacing is in inches and is the minimum
allowable. Additional spacing should be considered for ease
of installation, servicing, and compliance with local codes
and ordinances.
If closet door is installed, the minimum unobstructed air opening
in the top and bottom is required. Louvered doors with equivalent
air openings are acceptable.
The dryer must be exhausted outdoors.
No other fuel-burning appliance may be installed in the same
closet as the dryer.
Minimum Installation Clearances
15"
(381 mm)*
0" (0 mm)
Recessed front view
*Additional clearances for wall, door, and floor moldings may be required
or if external exhaust elbow is used.
48 in
2
.
(3.10 m
2
)*
Front
View
24 in
2
(1.55 m
2
)*
*Opening is the minimum for a closet door.
Louvered doors with equivalent air openings are acceptable.
14"
(356 mm)
max.
Closet
door
0" (0 mm)
1" (25 mm)
Closet side view
3" (76 mm)
Closet
Closet
door
door
3" (76 mm)
Product Dimensions 27" (68.6 cm) dryer
5
7
⁄
"
8
(152 mm)
2" (51 mm)
35"
(889 mm)
(25 mm)
3
(89 mm)
27" (686 mm)
ELECTRIC
BACK
VIEW
13"
(330 mm)
4" (102 mm)
dia.
GAS
EXHAUST
1
1
⁄
"
4
(32 mm)
29" (736 mm)
27
1
⁄
" (695 mm)
4
SIDE VIEW
LEFT OR
10
⁄
"
1
RIGHT SIDE
4
(260 mm)
EXHAUST
4
1
⁄
"
4
1"
(108 mm)
1
⁄
"
2
13
1
⁄
"
2
(343 mm)
6
1
⁄
"
4
(159 mm)
28
3
⁄
"
4
(733 mm)
3
1
⁄
"
4
(83 mm)
BOTTOM
EXHAUST
5
