8.5 8-way relay module
102
Dimension sheet
Fig. 40: Dimension sheet for 8-way relay module
Dimensions and weight
Specification
Weight
Length
Width
Height
Connection and power values
Specification
Voltage
Tolerance
Current consumption, max. (at 12 V)
Power consumption, max.
Ambient conditions during operation
Specification
Temperature range
Relative humidity
(not condensed)
Value Unit
180 g
85 mm
128 mm
65 mm
Value Unit
12–24 V DC
± 15 %
0,14 A
1,7 W
Value Unit
-25–+70 °C
10 – 95 %
