Install a cascade module in each switch.
Set one switch (and only one) to be the
base unit, as described in Installing the
BayStack 400-ST1 Cascade Module.
Cascade A Out
Cascade A Out
7
Connect the cascade cables, as described
in Installing the BayStack 400-ST1
Cascade Module.
To complete the switch installation, go to
"Attaching the switch to the wall" on
page 15.
