SW24.D
Controllable actuators
Ref. Description
EAM2 EKKO 300D 24V 3 m swinging gate linear actuator
EAM3
EKKO 400D 24V 4 m swinging gate linear actuator
EIM1 HIDDY 200D 24V 2 m swinging gate underground
Button functions and menu browsing
Button Description
Button to turn on the display, to access the menu and to con-
firm the parameter value change. When the motor is moving,
OK
when pushed once it displays the absorption in A of motor M1,
when pushed twice it displays the absorption in A of motor M2
▲ Button to scroll up the menus and increase the parameter value
Button to scroll down the menus and decrease the parameter
▼
value
Button to turn off the display, exit the menu and cancel the
ESC
parameter value change
51 Step-by-step command button
Preliminary checks:
After powering the unit, the name of the control board written as SW2.D,
the firmware version FX.XX and 3 flashes with the word FLSH appear in
the display, then display then goes off.
Check the diagnostic LEDs of the inputs, the LEDs 61, 62, 63 must be on.
If one of the safety inputs (61, 62, 63) is not used, insert a bridge between
the common (99) and the unused input.
If one of the safety inputs (61, 62, 63) is open, the dot at bottom right-hand
corner of the display flashes to indicate a engaged/non-working safety that
will prevent the gate from moving. It will therefore be necessary to check
the connections and the correct functioning status of the safety devices.
Menus
The control board programming is organized in menus and submenus
that allow to access and edit the parameters and logics of the control
board. The control board features the following first level menus:
Menu Description
LRNE Quick gate travel calibration
LRNA
Advanced gate travel calibration
PAR Control board parameter setting menu
RAD Remote controls management menu
DEF
Factory reset menu
CNT Cycle counter menu
ALM Board alarms menu
PASS
Board protection level setting menu
Submenus
All submenus are described in the table below.
Quick gate travel calibration.
The calibration is fully self-performed and sets:
- Opening and closing slowdown to 30% of the total travel
- Opening delay between leaves to 3 s
- Closing delay between leaves to 6 s
It requires mechanical stops both on opening and closing
Rows highlighted in grey refer only refer to a double leaf instal-
lation, in a single leaf installations delays between leaves are
not programmed
Display
Button Phase description
msg
-
51 Wait for calibration procedure start
When button pressed: leaf 2 closing and search
51 CLS2
for leaf 2 closing stop
-
CLS1 Leaf 1 closing and search for leaf 1 closing stop
- LOC Electric lock activation to free leaf 1
Leaf 1 opening travel measurement at slow down
-
OPN1
speed
Leaf 2 opening travel measurement at slow
- OPN2
down speed
Leaf 2 closing at normal speed and then at slow
- CLS2
down speed up to leaf 2 closing mechanical stop
Leaf 1 closing at normal speed and then at slow
-
CLS1
down speed up to leaf 1 closing mechanical stop
Full opening and closing of both leaves for cur-
- oooo
rent thresholds measurement
- END End of procedure
Advanced gate travel calibration.
Calibration allows the installer to set:
- Opening and closing slow down position
- Leaves end of travel positions
- Opening and closing delays between leaves
- Pedestrian opening position
It requires mechanical stops on closing only
Rows highlighted in grey refer only refer to a double leaf instal-
lation, in a single leaf installations delays between leaves are
not programmed
Display
Button Phase description
msg
- 51 Wait for calibration procedure start
When button pressed: leaf 2 closing and
51 CLS2
search for leaf 2 closing stop
Leaf 1 closing and search for leaf 1 closing
- CLS1
stop
-
LOC Electric lock activation to free leaf 1
Leaf 1 opening start.
When button pressed: leaf 1 opening slow
51
OPN1
down position setting, the leaf proceeds at
slow down speed
Leaf 1 opening slow down.
When button pressed: leaf 1 opening stop
position setting, if 51 is not pressed, the leaf
51 SLO
learns as the opening stopping position the
one obtained from the opening mechanical
stop
Leaf 2 opening start.
When button pressed: leaf 2 opening slow
51 OPN2
down position setting, the leaf proceeds at
slow down speed
Leaf 2 opening slow down.
When button pressed: leaf 2 opening stop
position setting, if 51 is not pressed, the leaf
51 SLO
learns as the opening stopping position the
one obtained from the opening mechanical
stop
Leaf 2 closing start.
When button pressed: leaf 2 closing slow down
51
CLS2
position setting, the leaf proceeds at slow
down speed
Leaf 2 continues closing at slow down speed
- SLO
up to closing mechanical stop
Leaf 1 closing start.
When button pressed: leaf 1 closing slow down
51 CLS1
position setting, the leaf proceeds at slow
down speed
Leaf 1 continues closing at slow down speed
- SLO
up to closing mechanical stop
Leaf 1 opening start.
0000 When button pressed: leaf 2 starts opening,
51 (second the control board learns and programs the
count) displayed opening delay between leaves. Leaf
1 and leaf 2 proceed to full opening
Leaf 2 closing start.
0000 When button pressed: leaf 1 starts closing,
51 (second the control board learns and programs the
count) displayed closing delay between leaves. Leaf 1
and leaf 2 proceed to full closing
- END End of procedure
