Intended Use
The garment is intended to keep the body warm in cold am-
bient temperatures.
Product Features
The numbering of the product features refers to the repres-
entation of the garment on the graphic pages.
(1) On/off switch and heat controller
(2) Battery adapter
(3) Heating elements
(4) Connector plug
(5) Inside pocket for battery adapter
(6) Inside pocket for large documents
(7) Battery A)
(8) Battery release button
(9) Socket for connector plug
(10) Belt clip
(11) USB port
(12) Activation button for USB connection
A) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Heated jacket
Article number
Sizes
Voltage V
Battery adapter
Article number
USB connection
– Charging voltage V
– Charging current A
Battery
Permitted ambient temperature
– While charging °C
– During operation A) and °C
during storage
Recommended batteries
Recommended chargers
A) Limited performance at temperatures <0 °C
Preparing the Garment
Charging the Battery
The battery adapter does not serve as a charger. Do
u
not use any in-car USB charging cables to charge the
Bosch Power Tools
battery. Using in-car USB charging cables can damage
the battery and/or the battery adapter.
Note: The battery is supplied partially charged. To ensure
full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.
Do not continue to press the on/off switch after the
u
heating elements have been automatically switched
off. This can damage the battery.
Inserting and Removing the Battery
(see figures A1–A2)
Do not use force to insert the battery. The battery is de-
u
signed in such a way that it can only be inserted into the
battery adapter when it is in the right position.
To insert the battery (7), push it all the way into the battery
adapter (2).
To remove the battery (7), press the release buttons (8) on
the battery and pull it out of the battery adapter (2).
Connecting Heating Elements
(see figures B1–B2)
GHJ 12+18V Unisex
Plug the connector plug (4) into the socket (9) on the bat-
1 600 A01 3..
tery adapter. The on/off switch (1) lights up briefly when the
XS/S/M/L/XL/2XL/3XL
battery is charged.
12
Slide the battery adapter (2) into the pocket (5) provided in
the garment or attach the battery adapter to your belt using
GAA 12V
the belt clip (10).
0 618 800 04J
USB 2.0
Using the Garment
5.0
1.0
Switching the Heating Function on/off
(see figure C)
Ensure that the battery (7) is charged and correctly inserted
0 to +45
into the battery adapter (2), and that the heating elements
(3) are connected.
–20 to +50
To heat, press the on/off switch (1) until the LED of the on/
off switch lights up red.
GBA 10,8V...
Note: The highest heating level is always set when the heat-
GBA 12V...
ing is switched on.
AL 11.. CV
To switch off, press and hold the on/off switch (1) until the
GAL 12.. CV
LED goes out.
Setting the Heating Level
The heating level is indicated by the colour of the LED on the
on/off switch (1).
LED
Red
English | 11
Thermal output
High
