INSTALLATION INSTRUCTIONS FOR ECO-SALT
INSTALLING THE POWER SUPPLY:
Select a convenient well-ventilated location within one metre of filter equipment and
mount the Power Supply vertically onto a post or wall 1.5 metres above ground level.
There are mounting hoses in the top and bottom of the unit to facilitate
installation. The Power Supply should not be located within 3 meters of the pool
water. Plug Power supply into a suitable weatherproof outlet or an independant
control box. The Unit must be kept away from acid and other chemical storage areas.
Acid and chemical vapours will corrode the electronics inside the Unit. It must also be
kept away from heat sources. Good ventilation is necessary for correct operation (See
installation diagram on page ).
Two self-tapping screws and wall plugs have been provided for fast and simple
installation. Use a 7mm masonry drill bit when fitting Power Supply to a brick or concrete
wall. When mounting to a post drill pilot holes and fit screws provided. Once screws are
in position simply hang chlorinator via bracket on back of Unit.
CONNECTING THE ELECTROLYTIC CELL TO THE POWER SUPPLY:
The Power Supply is fitted with a flexible lead terminated with connectors. These must
be correctly fitted to the connections on the underside of the Cell. Fit black connectors to
the outer titanium rods. Fit the white connector the middle titanium rod. The Blue Flow
Sensor should be pushed onto the thread of the small threaded bolt on the top of the
cell.
The power outlet on the bottom of the Power Supply (not on all models) is dedicated to
the POOL PUMP ONLY. Do not use a double adaptor to connect more than one pump -
it can cause overload to the system and could void your warranty. Important: The Cell
has to be connected as shown.
Note: The bolt included in one of the cell adaptors is for a connection to an
independent earth.
IMPORTANT: Do not operate the unit with pool isolation valves closed as possible
pressure build-up may cause the cell the break open. Such damage will not be
covered under warranty. For valve use, refer to your pool installer/builder.

PRE - START UP PROCEDURE:

Before operating your EcoSalt ensure the following items have been added to your pool:
• SALT - Load salt into the pool at a minimum rate of 40kg per 10,000 litres (0.4%).
