DVT67/2 SET
Both monitors of the DVT67/2 SET have already been paired with the
outdoor station on channel No. 1, one with the upper and one with the
lower doorbell button. Each doorbell button can be paired with a
second monitor.
To pair a second monitor with a doorbell button of the DVT67/2 SET
outdoor station (channel No. 1), proceed as described above (DVT67
SET), with the exception that the doorbell button has to be pressed
during the pairing.
!
Press the pairing button [27] on the outdoor station, until you hear
a long beep (when the outdoor station is battery operated, three
short beeps can be heard).
!
Press the doorbell button you wish to pair. The selection is
confirmed by a flashing of the respective doorbell button. Now you
have got one minute to do the pairing.
!
To pair a monitor with a second outdoor station, select channel No.
2.
Information about operation following extension:
!
If there is a ring at one of two outdoor stations, you can see at the
top left of the camera image where the ring has come from:
outdoor station "1#" or "2#".
!
When there is a ring at one of the outdoor stations, all of the paired
monitors that are switched on respond as described in section 11.1.
!
If there is a ring at an outdoor station and the conversation is
accepted on one of two paired monitors, the camera image
switches off on the other monitor, the start screen appears on it
and the screen switches off after approx. 20 seconds.
13. Settings
13.1 Settings adjusted directly by the buttons on the
monitor
!
Press any button [8/9/10/11/12/13] on the monitor to make the
start screen appear.
Volume of the ring tone on the monitor
!
Pressing the
and
volume of the ring tone on the monitor (1 to 9 bars).
Factory setting: 6 bars
Screen brightness
!
Pressing the
and
brightness of the screen (1 to 9 bars).
Factory setting: 3 bars
13.2 Menu settings
Scrolling through the menu
!
To open the menu, first press any button [8/9/10/11/12/13] on
the monitor to make the start screen appear, then press the menu
button
[9] . The menu items appear underneath one another.
36 - GB
buttons [8] reduces or increases the
buttons [8] increases or reduces the
!
By pressing the
and buttons [8], you can scroll between
the menu items and through the sub-menu of a menu item.
!
To select a menu or sub-menu item, press the menu button
!
By pressing the
and
existing setting.
!
To save the settings, press the menu button
!
To return to the menu from a menu item or to close the menu,
press the
button
[10]
!
Approx. 15 seconds after a button is pressed, the menu closes
automatically, and after approx. 5 seconds the screen switches
off.
VOLUME
of the ring tone / conversation / ring and camera display
duration on the monitor
Talking Volume
Setting for the loudspeaker volume on the
monitor (1 to 9 bars)
Factory setting: 6 bars
Ringtone Volume Setting for the ring tone volume on the
monitor (1 to 9 bars)
Factory setting: 6 bars
Ringing Time
Setting for
B
the duration of the ring tone on the monitor
between 0 and 30 seconds. (A setting of 0
seconds means that the ring tone is switched
off.)
B the camera display duration
30 seconds. A setting between 1-14 seconds
will automatically set the duration to 15
seconds
Factory setting: 30 seconds
BRIGHTNESS
of the screen
Setting the screen brightness (1 to 9 bars)
Factory setting: 3 bars
KEY TONE
Activation (ON) and deactivation (OFF) of the confirmation tone each
time a button is pressed
Factory setting: ON
RING TONE
Selection of the monitor ring tone (from 3 tunes)
Factory setting: Ring Tone 1
SNAP SET
- snapshot activation
Activation (ON) and deactivation (OFF) of automatic saving of a
snapshot when the doorbell button [25] on the outdoor station is
pressed. The snapshot is saved on the monitor.
Factory setting: ON
buttons [8], you can change the
.
.
between
.
15
and
