Placing speakers

Set up the speakers in the room using the following diagram as a reference.
For information on other speaker systems, refer to "Owner's Manual".
5.1-channel system
4
2 2
En En
1 2
9 3
10° to 30°
5
10° to 30°
7.1-channel system
(RX-V573 only)
1 2
9 3
4
10° to 30° 10° to 30°
6 7
30 cm (1 ft) or more
1 Front speaker (L)
2 Front speaker (R)
3 Center speaker
4 Surround speaker (L)
5 Surround speaker (R)
6 Surround back speaker (L)
7 Surround back speaker (R)
9 Subwoofer
5
