Jenn-Air JJW6024HL Instructions D'installation page 4

Cabinet Dimensions - Flush Installation
Installed in Cabinet
1/4" (0.6 cm)
Top Cleat
A
B
C D
3/4" x 1" (1.9 cm x 2.5 cm)
width x minimum
thickness Side Cleat
3" x 1/2" (7.6 cm x 1.3 cm) or
3" x 5/16" (7.6 cm x 0.8 cm)
without bottom trim
height x width
Spacer (entire depth
of cutout)
e
A. 23 ⁄ " (60.2 cm) width of flush inset cutout (minimum)
11
16
B. 22" (55.8 cm) width of opening (minimum)
C. 18 ⁄ " (47.2 cm) height of flush inset cutout (minimum)
9
16
D. 18 ⁄ " (46.6 cm) height of opening (minimum)
3
8
E. 20 ⁄ " (51.8 cm) depth of cutout (minimum)
3
8
NOTE: True dimensions are in cm and converted to inches.
4
E
e
Installed under Counter
(Without cooktop installed above)
e
C
3/4" x 1" (1.9 cm x 2.5 cm)
width x minimum thickness
3" x 1/2" (7.6 cm x 1.3 cm) or
3" x 5/16" (7.6 cm x 0.8 cm)
without bottom trim
(entire depth of cutout)
A. 23 ⁄ " (60.2 cm) width of flush inset cutout (minimum)
11
16
B. 22" (55.9 cm) width of opening (minimum)
C. 18 ⁄ " (47.2 cm) height of flush inset cutout (minimum)
9
16
D. 18 3 ⁄ " (46.6 cm) height of opening (minimum)
8
e. Recommended junction box location
Top View
Side Cleat
JJW6024HM: 13/16" (20.5 mm)
JJW6024HL: 7/8" (21.3 mm)*
A. 20 ⁄ " (51.8 cm) depth of cutout (minimum)
3
8
*True dimensions are in mm and converted to inches.
1/4" (0.6 cm)
Top Cleat
A
B
D
Side Cleat
width x height
Spacer
Side Cleat
e
A
