A: One Sheet of paper
(standard position)
B: Copy paper
Fig. 2-6 Position of the adjust lever
(SP347)
2.25 inch
Paper
guide 3 inch
3.35 inch
Fig. 2-8 Roll paper guide (SP347)
Fig. 2-9 Raise the auto cutter (SP347)
Paper guides
Adjust lever
Paper guide shaft
5 Set the left and right paper guides.
Paper
guide
Auto cutter
6 Lift up the auto cutter and put it in a
– 8 –
Roll paper
holders
Lock lever
For 2.25-inch
paper
Paper holder
mount notch
for 3-inch
paper
Fig. 2-7 Mounting the roll paper
holders (SP347)
Leave a 0.5 mm gap between the
paper guide and the edge of the
paper and fix the lock lever.
• When you insert the stop ring that
corresponds to the groove of the
paper guide shaft shown in Fig. 2-
8, that will be the position when
you set the paper guide.
vertical position, as shown in Fig. 2-
9.
Paper holder
mount notch
for 3-inch
paper
For 2.25-inch
paper
