supervision or instruction.
b) Children being supervised not to play with the
appliance.
c) Do not recharging non­rechargeable batteries!
d) During charging, batteries must be placed in
the well ventilated area!

2. MACHINE INFORMATION

Intended use
The machine is intended for sawing wood, metal,
plastics, ceramics, rubber, etc. to any required size
and in any required shape, while keeping the ba-
seplate resting firmly on the workpiece. A suitable
saw blade must always be used.

TECHNICAL SPECIFICATIONS

Model No.
Rated voltage
No load speed
Saw stroke
Max. saw capacity wood 0°
Max. saw capacity steel 0°
Weight
Sound pressure level L
Sound power level L
WA
Vibration 'sawing sheet metal' 5.459 m/s
Vibration 'sawing plywood'
Model No
Battery Type
Voltage
Capacity
Recommended charger
Weight
Model No
Charger input
Charger output
Charging time 2Ah battery
Charging time 4Ah battery
Recommended batteries
Weight
8
S_JS501DC
20V
0-2500/min
25mm
50mm
8mm
1.85 kg
82.0 dB(A), K=3dB(A)
PA
93.0 dB(A), K=3dB(A)
K=1.5 m/s
2
5.658 m/s K=1.5 m/s
2
CD801AA
Lithium-Ion
20V
2.0 Ah
CD802AA
0.3 kg
CD802AA
220-240V,50Hz 0.4A
21V 2.5A
60 minutes
120 minutes
CD801AA, CD803AA
0.36 kg
Only use the following batteries of the VONROC VPO-
WER 20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CD801AA
CD803AA
The following charger of the can be used to charge
these batteries.
CD802AA
The batteries of the VONROC VPOWER 20V battery
platform are interchangeable with all the VONROC
VPOWER 20V battery platform tools.
Vibration level
The vibration emission level stated in this instruc-
tion manual has been measured in accordance
with a standardized test given in EN60745; it may
be used to compare one tool with another and as
a preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories, may
significantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
2
your hands warm, and organizing your work patterns.
2
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. Lock-off button
2. On/off switch
3. Handle
4. Battery
5. Battery unlock button
6. Pendulum action switch
7. Scale for bevel angle
8. Baseplate cover
9. Baseplate
10. Guide roller
11. Laser switch
12. Guard
13. Clamping lever
14. Wing bolts for parallel guide
15. Hex key
16. Chuck
20V, 2Ah Lithium-Ion
20V, 4Ah Lithium-Ion
Quick charger
