Other inputs - AUX
1. In the wireless connection mode, insert RCA audio cable into AUX input port on the rear
panel of the right speaker (pay attention to L/R connector matching); then connect RCA
audio cable to audio source devices with RCA output port.
(please ensure the left and right speakers have been paired)
L
AUX
R
- +
-2 +2 -1 +1
-4 +4 -2 +2
-6 +6 -3 +3
DESIGNED BY PHIL JONES
Right speaker
2. Slide the "INPUT SELECT" switches to the "OTHERS" positions on the rear panels of both
speakers, and press the "AUX" button on the remote control or press the "VOLUME" dial
on the rear panel of the right speaker to select AUX input, LED display window on the right
speaker will display "AUX".
Right speaker
Left speaker
INPUT SELECT
- +
OTHERS
+6
+3
0
-3
-6
+3
-2 +2 -1 +1 +1
0
-1
-4 +4 -2 +2
-3
-6 +6 -3 +3
3. Play music on the connected device, and press the "+"/"-" button on the remote control
DESIGNED BY PHIL JONES
or press the "VOLUME" dial on the rear panel of the right speaker to adjust volume to a
desired level.
or
4. Use the treble/bass button on the remote control to adjust treble/bass to a desired level OPT COAX
in terms of room size and your preference. AUX
AUX
BASS TREBLE
BASS
CD player
CD player/audio decoder/
music player, etc.
OPT COAX
AUX
BASS TREBLE
or
AUX
- +
-2 +2 -1 +1
-4 +4 -2 +2
-6 +6 -3 +3
DESIGNED BY PHIL JONES
OPT COAX - +
-2 +2 -1 +1
TREBLE
-4 +4 -2 +2
-6 +6 -3 +3
DESIGNED BY PHIL JONES
15
Other inputs - optical/coaxial
1. In the wireless connection mode, connect the right speaker to audio source device with
optical or coaxial digital output port using fiber optic input audio cable (or coaxial cable) .
(please ensure the left and right speakers have been paired)
Right speaker
COAX
- +
or
-2 +2 -1 +1
-4 +4 -2 +2
-6 +6 -3 +3
OPT
DESIGNED BY PHIL JONES
2. Slide the "INPUT SELECT" switches to the "OTHERS" positions on the rear panels of both
speakers, and press the "OPT" (or "COAX") button on the remote control or press the
"VOLUME" dial on the rear panel of the right speaker to select optical (or coaxial) input,
LED display window on the right speaker will display "OPT" (or "COAX") .
Right speaker
Left speaker
INPUT SELECT
- +
OTHERS
+6
+3
0
-3
-6
+3
-2 +2 -1 +1 +1
0
-1
-4 +4 -2 +2
-3
3.Play music on the connected device, and press the "+"/"-" button on the remote control or -6 +6 -3 +3
DESIGNED BY PHIL JONES
press the"VOLUME" dial on the rear panel of the right speaker to adjust volume to a desiredlevel.
4. Use the treble/bass button on the remote control to adjust treble/bass to a desired level
OPT COAX
in terms of room size and your preference.
AUX
BASS TREBLE
* Only the standard PCM audio signals (44.1KHz/48KHz/96KHz/192KHz) function in optical
or coaxial mode.
* If the optical digital output of playing device is ACC, such as on a TV, please switch it to PCM.
TV/CD player/
Blu-ray player, etc.
OPT
OPT COAX
or
COAX
AUX
BASS TREBLE
or
OPT or COAX
- +
-2 +2 -1 +1
-4 +4 -2 +2
-6 +6 -3 +3
DESIGNED BY PHIL JONES
or
OPT COAX
- +
AUX
BASS TREBLE
-2 +2 -1 +1
-4 +4 -2 +2
-6 +6 -3 +3
DESIGNED BY PHIL JONES
