The remote control system

Here you get an overview of the remote control system of your Metabo Quadcopter and its various features
and settings. Before the fi rst fl ight, you should absolutely have read and understood all these functions and
EN
settings.
• Do make sure that the transmitter is turned off - POWER-LED off.
• Now open the battery compartment cover on the backside of the transmitter. Slide the cover down and
insert three size AA Alkaline batteries.
• WARNING: pay attention to the correct polarity - fi re or explosion hazard!
• Close the battery compartment cover, then turn on transmitter.
• The POWER LED must lit. Attention: if the POWER LED fl ashes and a beep sound appears or does not
light at all, the model may not started – crash hazard! Change transmitter batteries immediately.
• WARNING: check the POWER LED also during operation. If the POWER LED starts to blink and
the sound appears, stop operation, switch the model off and replace the transmitter batteries – crash
hazard!
• ATTENTION: The maximum range of the remote control system is about 50 meters, do not fl y
farther away under any circumstances - crash hazard!

Transmitter

Throttle lever
(Rise/sink,
yaw left/right)
Lights

Battery charging

WARNING: Be sure to read all safety instructions regarding the use of rechargeable batteries. Charging
may take place only with the supplied charger on a fi reproof surface and under constant adult supervision -
fi re or explosion hazard!
USB Charger
18
Speed Flips
COM P U TE R
U S B
The remote control system · Battery charging
-
+ +
- -
+
Direction lever
(forward/backward,
left/right)
Headless Mode
Power-LED
Power Switch (ON/OFF)
LiPo battery
Metabo Quadcopter
