Installing your new appliance
In case your home access door is too
narrow for the refrigerator to pass
through, remove the refrigerator doors
and drawers.
Tools you will need(Not provided):
Allen Wrench (5/32'' , 4mm)
Philips Screwdriver
Refrigerator Door Removal
1. With the door closed, remove the 3
screws holding the top cover (1) with
Philips(+) screwdriver, and then remove
the top cover.
2. Remove the screws(2) fixed on the
upper hinges with a wrench(5/16'' , 8mm)
and the ground screw(3) attached to
the hinge with Phillips(+) screwdriver.
Remove the upper left and right door
hinges(4).
Wrench (5/16'' , 8mm)
1
3
4
3. Use both hands to open the door
more than 90°. Lift it up and take it off.
4. Remove the screws(5) fixed on the
middle hinges with a allen
wrench(5/32'' , 4mm) and the screw(6)
fixed on the middle hinges with
Phillips(+) screwdriver. Remove the
middle left and right hinges(7).
6
2
7
5
