Contents
1x CUBID 12 V / 0.5 W
Dimensions 50 x 53 x 50 mm / 2.0 x 2.1 x 2.0 inches
1x Easy-Lock
2x screws
1x removal tool
1x template
Material
Aluminium housing
Polycarbonate lens
Please read the following instructions before installing. You are
advised to keep these installation instructions in a safe place.
Although a 12 V system is safe, we advise you to have a qualified
electrician check the installation.
Use
Wall-mounted light fixture for installation near steps, sunken sitting
area, fence, etc.
Lamp
The fixture is equipped with a high-quality LED lamp. These lamps
have a long life (about 50,000 hours) and a high light output and their
power consumption and the heat produced are extremely low.
Important!
Never connect the low-voltage cable directly to a 100-240 V power
source. It is only suitable for use in combination with a 12 V low-voltage
system. This product should only be used within the in-lite system. Use
of products other than those made by in-lite will invalidate the warranty.
Enjoy the lighting in your yard.
EN
Connecting the fixture to 12 V
The already installed lamp means the fixture is immediately ready for
use. Therefore you do not need to install the lamp first.
Step 1
Remove the mounting plate (A) using the removal tool (B). (Fig. 1)
There is a hole in the middle of the mounting plate to feed the cable
through. Make a hole of at least 13 mm / 0.5 inch Ø in the mounting
surface in the position where you want to mount the fixture to feed the
cable through. You can use the supplied template. Attach the mount-
ing plate to the surface with the screws provided. (Fig. 2)
Note: retain the removal tool in case you want to move the fixture in
the future.
Step 2
Hook the fixture over the rim of the mounting plate and click the fixture
back into place against the mounting plate. (Fig. 3)
Step 3
Join the Easy-Lock connector to the main cable. (Fig. 4)
a. There are two cable grips. The grip with the wider recess fits the
10/2 main cable, the grip with the narrower recess fits the 14/2
main cable. Clamp the correct cable grip over the main cable.
b. Put the cable grip (with the cable underneath) in the Easy-Lock
connector.
c. Tighten the threaded cap on the Easy-Lock connector. This will
cause the contacts to be pushed through the insulation on the
cable. In tightening the cap, a little gel is applied to the contacts in
the Easy-Lock connector. This serves to protect the contacts
against moisture. A little gel may possibly come out of the Easy-
Lock connector: so after installation (and/or before a meal), wash
your hands with soap and water, and avoid the gel coming into
contact with your eyes.
Step 4
Connect the main cable to the fixture by connecting the mini-
connector. (Fig. 5)
If the lamp does not work correctly, check that the Easy-Lock connec-
tor is properly connected to the main cable. Do the same for the mini-
connector. Repeat steps 3 and 4. When the fixture is connected to the
main cable also check that the contacts of the Easy-Lock connector
are not bent. If you have any problems, contact your dealer.
General maintenance advice
We advise wiping the fixture down at least once a year using a clean
cloth and warm water.
