BoomToneDJ Dymano Scan LED Mode D'emploi page 13

4. How To Set The Unit
To select any of the given functions, press the MENU button up to the required one is shown
on the display. Select the function by ENTER button. Use DOWN and UP button to change
the mode. Once the required mode has been selected, press the ENTER button to setup or
it will automatically return to the main functions without any change after idling 10 seconds.
To go back to the functions without any change press the MENU button. The main functions
are shown below:
Control Panel :
main menu display content
1
2
3
4
5
6
7
DMX512 (enter switch to the channel mode selection) /
A001
Slave MODE
Running mode select X (SOUD is sound control, FAST
RUNx
is fast running, SLOU is slow running)
Manually adjustable strobe light, enter Switching a
LEdF different color mode(LXXX is LED Manually dimmer,
FXXX is Stroboscopic and speed regulating switch
Manually set the various parameters of the machine,
enter switch between different motor patterns, PXXX is
StEP
PAN adjustment, TXXX is TILT adjustment, CXXX is
Color adjustment, 9XXX is GOBO adjustment.
Leon/Loff Switch between display always ON or OFF after 1 min.
rest Back to factory presets
load Reset of the Unit
function
12
