Whirlpool WED85HEFW Instructions Pour L'installation page 17

4.
Remove outer window assembly
from trim ring
Using a Phillips screwdriver, remove the 2 screws from the
outer window retainer and rotate the outer window assembly
clockwise until the square notches line up with the 4 tabs
on the trim ring indicated with arrows in the figure A above.
Then lift out the outer window and retainer up and off the trim
ring and set aside (B).
5.
Reverse outer window assembly
Handle
Fig. A
Fig. B
Using a Phillips screwdriver, remove the 4 screws from the
outer window retainer and lift off the trim ring off the window
(A). Rotate trim ring 180° and secure with the 4 screws
removed earlier (B).
Fig. A
Handle
Fig. B
17
