6)
The wire will emerge from the far end of the torch , then feed the tip onto the wire (make
sure the tips is the correct size for the diameter of wire being used ) tighten it and replace the shroud
2.
Fitting cylinder mounting bracket . To fit the gas cylinder –mounting bracket (where provided
) ,fit the brackets to the rear of the machine
3.
Connecting the gas tube to the regulator
Connect the gas tube by pushing the free end into the connector on the regulator, If necessary the tube
can be detached again by pushing the tube and the small ring around it into the fitting, and then pulling
the tube whiles maintaining pressure on the ring
4.
Fitting the gas regulator according to the disposable cylinder
Before starting check that the gas flow valve knob on the regulator is turned off (fully clockwise) to
avoid excessive gas escape
2)
Remove the cover from the cylinder thread. Make sure your eyes are protected and carefully
screw on the regulator. Note, gas will escape until the regulator is fully fitted.
3)
IMPORTANT: Always detach the regulator from the cylinder when you have finished welding.
This will avoid small leakages that may occur in time which will empty the cylinder in the long term
3.
stetting the gas flow regulator
Turn the control knob fully clockwise and then turn back anti-clockwise approximately 1/2 to 1 turn
depending on welding conditions.
For the larger MIG welders, a large gas cylinder regulator is needed, this regulator is supplied with a
fitting suitable for connecting the regulator to a CO2 and a second suitable for connecting to an
argon/co2 mixed gas cylinder
HOW TO USE
Before welding ensure that:
• All flammable materials and containers have been removed from the work area
• There is good ventilation , particularly at the front and rear of the welder
• There is an adequate fire-fighting appliance close by
• Please install the machine according to the following steps.
• Ensure power is disconnected before any connection operation
• Make sure the machine is always grounded while working.
• Please avoid using the machine in rain
MIG welding installation and operation
Make sure the input power cable is tightly connected to the correct socket of source power.
1)
Plug in MIG torch , (A) for gas welding (use solid wire), connect "fast connector " to "+", earth
clamp connect to "-". (B)For gasless welding (use flux cored wire) , connect "fast connector " to "-" ,
earth clamp connect to "+" .
2)
Ground connection is needed for safety purpose
3)
Switch on the machine , then select MIG function
4)
Press the button of "Wire transport" to get the wire transported out.
Varan Motors
BCIE SARL, gruuss-strooss 28, 9991 Weiswampach, Luxembourg
T: 00352/26908036 – F: 00352/26908040
VAR-MIGMMA160
VAR-MIGMMA200
