Technical Data; Items Included - Bosch Power Tools GCO 14-24 Professional Notice Originale

10 | English
(4) Retracting blade guard
(5) Spindle lock
(6) Cutting disc
(7) Angle guide
(8) Locking spindle
(9) Quick release
(10) Spindle handle
(11) Mounting holes
(12) Hex key (8 mm)
(13) Base plate
(14) Locking screw for angle guide
(15) Transport safety lock
(16) Tool arm
(17) Transport handle
(18) Protective guard
(19) Spark guard plate
(20) Tool spindle
(21) Clamping flange
(22) Washer
(23) Hexagon screw

Technical Data

Cut-off grinder
Article number
Rated power input
No-load speed
Weight according to EPTA-
Procedure 01:2014
Protection class
Permitted workpiece dimensions (maximum/minimum): (see "Per-
missible workpiece dimensions", page 12)
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Dimensions of suitable cutting discs
Max. cutting disc diameter
Max. cutting disc thickness
Hole diameter
Assembly
Avoid starting the power tool unintentionally. The
u
mains plug must not be connected to the power supply
during assembly or when carrying out any kind of
work on the power tool.

Items included

Carefully remove all parts included in the delivery from their
packaging.
1 609 92A 6CW | (18.01.2021)
Remove all packing material from the power tool and the ac-
cessories provided.
Check to ensure that all the parts listed below have been
supplied before using the power tool for the first time:
– Cut-off grinder with cutting disc fitted
– Hex key (12)
Note: Check the power tool for possible damage.
Before continuing to use the power tool, carefully check that
all protective devices or slightly damaged parts are working
perfectly and according to specifications. Check that the
moving parts are working perfectly and without jamming;
check whether any parts are damaged. All parts must be fit-
ted correctly and all the conditions necessary to ensure
smooth operation must be met.
If the protective devices or any parts become damaged, you
must have them properly repaired or replaced by an author-
ised service centre.
Stationary or flexible mounting
To ensure safe handling, the power tool must be
u
mounted on a flat, stable work surface (e.g. work
bench) before use.
Mounting on a work surface (see figure A)
– Use suitable screw fasteners to secure the power tool to
the work surface. Use the holes (11) to do this.
Flexible installation (not recommended)
GCO 14-24
In exceptional circumstances, if it is not possible to securely
3 601 M37 1..
mount the power tool on a work surface, you can improvise
by placing the feet of the base plate (13) on an appropriate
W 2400
base (e.g. workbench, flat ground, etc.), without screwing
-1
min 3800
down the power tool.
kg 17.0
Changing the Cutting Disc (see figures B1 − B2)
/ II
Pull the plug out of the socket before carrying out any
u
work on the power tool.
Do not activate the spindle lock (5) while the tool
u
spindle (20) is moving. The power tool may become
damaged if you do this.
Do not touch the cutting disc after use until it has
u
cooled. The cutting disc becomes very hot during use.
mm 355
Only use cutting discs that match the specifications given in
mm 3
this operating manual and that have been tested and marked
in accordance with EN 12413.
mm 25.4
Use any intermediate layers provided with the cutting disc.
Place unused cutting discs in an enclosed container or their
original packaging. Store the cutting discs lying flat.
Removing the cutting disc
– Bring the power tool into the work position.
– Swivel the retracting blade guard (4) backwards as far as
possible.
– Turn the hexagon screw (23) using the hex key (12)
provided while pressing the spindle lock (5) until it en-
gages.
– Hold the spindle lock down and unscrew the hexagon
screw (23).
