Emergency
Downlight
EM250B
User Instruction
EM250B REC 2S
3.2V 6.4Ah
OA/CO NM3 ELW
Dimensions (mm)
2
Inrush current
I mains (A)
I max
max/2
Tref
2025-08-18 V1
© Signify Holding
All rights reserved
SL wire
220V
50Hz
240V
60Hz
Battery
Duration
3H
196
Inom (mA)
Imax (A)
Tref (µs)
MCB
B-10 A
B-13 A
B-16 A
I nom.
C-10 A
C-13 A
Time (us)
C-16 A
Oval lens.
(Round lens is mounted).
indoor
Test
Operation Mode
Maintained &
Interact
Non-Maintained
75
Electrical
characteristics
41
12.6
166
Luminarie
Max.
39
63
66
105
1/8
Battery
Converter
LEDs
IP20
Lumens output
205 lm (Round lens)
200 lm (Oval lens)
212
- The luminaire shall be installed by a qualified electrician and wired in
accordance with the latest IEE electrical regulations or the national
requirements.
- The light source of this luminaire is non-user replaceable, the light
source can be replaced by manufacturer, service agent or silimar
qualified person.
- The battery of this self-contained emergency luminaire is not a user
serviceable item and shall be replaced by a competent person, a
manufacturer or the manufacturers service agent.
- Clean with dry cloth.
- Philips Lighting warranty is applicable only if the indicated drivers are
used.
Data subject to change without notice
Keep for future reference: www.lighting.philips.com/lighting
Max.
IK04
45°C
Min.
0°C
P (W)
Net Weight
5
0.46 kg
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
