PARTS LIST

Please refer to the Schematic Drawing, on the preceding page.
N
O.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
WARNING: Repairs should be made by an authorized repair centre. Opening this
!
tool could invalidate your warranty.
NOTE: Due to continuous product improvement, we reserve the right to change the
!
product specification without prior notice.
DESCRIPTION
Mallet
Strike cap
O-Ring 25 X 3.55
Bolt M5 X 25
Washer
Air Cap
Spring
O-Ring 55.2 X 1.8
Lining Ring
O-Ring
Washer
Bolt M4 X 20
Washer 4
Poppet Actuator
Retainer Ring
Lock Ring
O-Ring 28 X 2.65
O-Ring 50 X 2.65
Lining Ring For Poppet
Cylinder Bushing
O-Ring 12.8 X 2.5
O-Ring 42 X 4.6
O-Ring 10 X 1.8
Poppet
O-Ring 15.6 X 1.8
Piston Rod
Driver Blade
Piston
O-Ring 50 X 3.55
Bumper
Gasket
Gasket
Body
Pin 6 X 20
Nose
N DESCRIPTION
O.
36 Shoe
37 Washer 6
38 Bolt M6 X 35
39 Foot plate
40 Bolt M6 X 14
41 Bolt M5 X 10
42 Bolt M5 X 14
43 Magazine Hanger
44 Bolt M6 X 20
45 Plate
46 Bolt M3 X 16
47 Driver Guide
48 Spring Hook
49 Spring
50 Magazine
51 Spring
52 Pin
53 E-Ring 3
54 Pusher
55 Tail Cover
56 Washer 4
57 Bolt M4 X 16
58 Spring
59 Side Load Magazine
60 Bushing
61 Fixture
62 Bolt M3 X 16
63 Gasket
64 Bolt M5 X 25
65 Handle
66 Lock Nut M8
67 Washer 8
68 Bracket
69 Arm
70 Hand Grip
71 Air Plug
