H - Electrical wiring diagrams and instructions

WARNING:
ONLY A QUALIFIED PERSON MUST INSTALL THIS APPLIANCE
All aspects of the installation must conform with the requirements of the standard North
American wiring rules, as well as your local electrical and building codes and regulations,
and any other applicable requirements or conditions of your local power supply authority.
A licensed electrician must perform the electrical work when installing this appliance. The
supply cable and fuse rating must be suitable for the appliance.
SEO76 Single Oven
Condominium Electrical Requirements: 208 Volt, 60hZ, 3460 Watt, 30 AMP
Residential Electrical Requirements: 240 Volt, 60hZ, 4580 Watt, 30 AMP
WARNING:
ovens are supplied with a 5' long electrical cable and must be hard wired to the
electrical supply.
licensed electrician must connect the armour cable and 3 wires into the electrical
connection box. The white, or Neutral wire is not used, and must be capped using a
marette.
To avoid power borne interference, this appliance must be installed individually on a separate and
distinct final sub-circuit.
Note:
To the electrician – please ensure sufficient supply cable is provided to allow the appliance to be
removed from the cavity should any servicing be necessary. This will also allow easy connection
of the supply.
Voltage supply connection
To connect the electrical supply:
1- Ensure the supply cable and fuse rating are suitable for the appliance (see electrical
loading).
2- Remove the cover plate by undoing the screw.
3- Fit a suitable entry bush to the conduit entry on the rear left of the appliance (with the rear
toward you) and feed the fixed wiring through.
4- Connect the wiring to the terminal block using the screw connections provided. Ensure
the wires are properly secured to prevent any high resistance electrical connection.
5- Replace the cover plate making certain that the supply wiring is clear of any metal work
and screws.
When connected to a sub circuit, protected by a circuit breaker, it is recommended the circuit
breaker be the same as the total rating of the appliance.
Do not use multi-plug adapters and extension cables
• Make sure not to cause damage to the main plug and to the main cable. Should the main cable
need to be replaced, this must be carried out by our Authorised Service Centre.
• Do not let main cables touch or come near the appliance door, especially when the door is hot.
ovens use Red and Black live wires and Green for ground. A
34
