FINAL ASSEMBLY INSTRUCTIONS
6. Feed the wires from the motor assembly (F) through
the center hole in the light kit housing (G).
Position keyhole slots on light kit housing (G)
around the loosened mounting screws and twist
clockwise. Re-install the previously removed
mounting screw, then tighten all screws securely.
7. Remove one of the preassembled screws from the
light kit housing (G) and loosen but do not remove
the other two screws.
8. Connect wires from the motor assembly (F) to the
light kit (H) - WHITE to WHITE and BLACK to
BLACK.
Position keyhole slots on light kit (H) around the
loosened screws and twist it clockwise. Re-install the
previously removed screw, then tighten all screws
securely.
6
F
G
7
G
8
12
G
Lowes.com/allenandroth
H
