Quick Installation Guide
Access Point Mount Accessory
Note: Images are for demonstration only, and may differ from your actual products.
© 2025 TP-Link 7100001268 REV1.0.1
Mount the AP
For additional rotation needs of the AP, connect the mount accessory between your AP bracket and mounting bracket.
Please note that this mount accessory is intended for use with APs weighing less than 5 kg.
Option 1: Pole Mounting
1
Option 2: Wall Mounting
1
2
3
2
3
In the Box
Vertical adjustment: ±45°
Note: The actual adjustment angle may be affected by the product antenna and installation position.
4
4
Horizontal adjustment: ±45°
5
5
