Bottom
Housing
4. Install the Soap Dish
Press the stop in place in the bracket.
Fit the housing over the bracket, and snap it into place.
Assemble the ring to the housing with the indent over the
housing tab.
Install the soap dish to the housing. Secure with the provided
screw.
088148-2-AB
Screw
Soap Dish
Ring
Larger Indent
Housing
Tab
Stop
Back View
6
