BXT 7- B 3
TILTING
PREMIUM TV WALL MOUNT
SUPPORT MURAL POUR TÉLÉVISEUR PREMIUM
INCLINABLE
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
Texte français page 24
Your TV product sticker may be inaccessible after
mounting your TV.
L'étiquette produit de votre télévision pourrait ne plus
être accessible après le montage de votre télévision.
BEFORE MOUNTING YOUR TV
AVANT LE MONTAGE DE VOTRE TÉLÉVISION.
Record your TV information and save for future reference.
Notez les informations concernant votre télévision et
conservez ces notes pour toute consultation ultérieure.
Or, take a photo of your TV product sticker and save for
future reference.
Sinon, prenez l' é tiquette produit de votre télévision en photo
et conservez la photo pour toute consultation ultérieure.
Brand:
Model No.:
Serial No. (S/N):
Version/SCC/Other:
Table des Matières
loading

Manuels Connexes pour Sanus ELITE BXT7-B3

Sommaire des Matières pour Sanus ELITE BXT7-B3

  • Page 1 Your TV product sticker may be inaccessible after mounting your TV. L’étiquette produit de votre télévision pourrait ne plus être accessible après le montage de votre télévision. BEFORE MOUNTING YOUR TV AVANT LE MONTAGE DE VOTRE TÉLÉVISION. Record your TV information and save for future reference. Notez les informations concernant votre télévision et conservez ces notes pour toute consultation ultérieure.
  • Page 2 ? Call us at: +1 (800) 359-5520 Watch it now at: Check it out at: Appelez-nous au : +1 (800) 359-5520 SANUS.com/3276 SANUS.com/2566 Regardez-la maintenant sur : Découvrez-le sur : Or, chat at: SANUS.com/chatSP SANUS.com/3276 SANUS.com/2566 Ou, discutez en ligne sur : SANUS.com/chatSP...

  • Page 3: Before You Begin

    Before you begin Remove the stand Install any accessories Protect the face from your TV — of your TV if attached. you may have purchased — if they require when laying it down for installation. the TV to be removed from the wall for assembly.

  • Page 4: Important Safety Instructions

    ● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use. If your TV (including accessories) exceeds this TV Weight Limit weight, this mount is NOT compatible. (including accessories) 300 lbs. Visit SANUS.com or call customer service to find a (136 kg) compatible mount. DO NOT EXCEED...

  • Page 5: Tools Needed

    Wall wood studs Solid concrete or CAUTION: concrete block Construction DO NOT install ONLY install on in drywall alone these acceptable wall types. Drywall alone will Call hold the weight Customer of your TV. Unsure Service ACCEPTABLE ACCEPTABLE Tools Needed 1/2 in.
  • Page 6 STEP 1 Attach TV Bracket to TV WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 7 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or with Irregular Back TV Extra Space Needed [TV brackets lay flat on your TV] [for deep inset holes...
  • Page 8 1.3 Determine Your TV Bracket Configuration Measure the HEIGHT of your TV mounting hole pattern. For Height For height 400mm or less greater than 400mm Assemble TV bracket Skip to STEP 1.4 extensions to fit over your on PAGE 9 TV VESA height.
  • Page 9 1.4 Attach TV Brackets to Your TV Center the TV brackets on your TV hole pattern, and install using your screw/washer/spacer. NO SPACER SPACER(S) NEEDED 2.5mm 5.0mm 7.5mm Adjust the straps the bottom of the TV. TV VESA ≤ 400mm shown...
  • Page 10 STEP 2 Attach Wall Plate to Wall WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 11 Determine Your Wall Plate Configuration Measure the distance between your TV brackets Extend your wall plate beyond your TV brackets but not past your TV edges. For TV brackets For TV brackets greater 700mm or less than 700mm WARNING: Avoid potential personal injuries! These areas could be pinch points when sliding back together.
  • Page 12 Wood Stud Installation STEP 2A CAUTION: Avoid potential personal Min. 1 ½ in. (3.8 cm) injury or property damage! ● Drywall covering the wall Min. 3 ½ in. (8.9 cm) Min. 16 in. (40.6 cm) must not exceed 5/8 in. (1.5 cm) ●...
  • Page 13 (top and bottom) of wall plate , then a minimum of 16 in. (406 mm) out from center, for a minimum of 6 lag bolts total. To calculate your precise wall plate location, check out our HeightFinder at sanus.com [www.sanus.com/3276]. TIP:...
  • Page 14 (continued) STEP 2A DRILL SECURELY TIGHTEN 2 ¾ in. (6.9 cm) Extended Wall Plate 7/32 in. (5.5 mm) CAUTION: Avoid potential personal injury or property damage! All lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate .
  • Page 15 6 lag bolts total. Min. 16 in. (406 mm) when selecting the wall plate Min. 16 in. (406 mm) location To calculate your precise wall plate location, check out our HeightFinder at sanus.com [www.sanus. TIP: TIP: com/3276].
  • Page 16 (continued) STEP 2B DRILL INSERT ANCHORS 3 in. (7.6 cm) 3/8 in. (10 mm) Be sure the anchors are seated flush with the CAUTION: CAUTION: CAUTION: CAUTION: Never drill into the mortar between blocks. Never drill into the mortar between blocks. concrete surface.
  • Page 17 SECURELY TIGHTEN Extended Wall Plate CAUTION: Avoid potential personal injury or property damage! All lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
  • Page 18 STEP 3 Attach TV to Wall Plate HANG ATTACH HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: TV brackets MUST remain centered in wall plate For extended wall plates: CAUTION: Avoid potential personal injury or property damage! TV brackets...
  • Page 19 Adjustments LEVEL HEIGHT To level your TV, turn the Adjust the height level adjustment screw by turning the level on the top of either TV adjustment screw RAISE bracket on the top of both TV LOWER RAISE RAISE raise or lower that respective brackets LOWER LOWER...
  • Page 20 TILT Your TV should adjust easily when moved, then stay in place. Adjust the tilt tension knob if your TV naturally tilts up or down. NOTE: If you do not intend to adjust the tilt for different viewing locations, you can tighten the tilt tension knobs prevent unwanted movement.
  • Page 21 TV LATERAL SHIFT CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: TV brackets MUST remain centered in wall plate Lift your TV up then carefully reposition on the wall plate. The wall plate has stops to limit lateral movement. Pull down AND HOLD both release tabs R while gently To unlock your TV: pulling the bottom of the TV away from the wall.
  • Page 22 REMOVING THE TV CAUTION: Avoid potential personal injury or property damage! To prevent breaking the locking latch: always pull and hold release tabs R down while pulling the TV away from the wall. NOTE: To rehang the TV, follow the procedures in STEP 3 on PAGE 18.

  • Page 23: Dimensions

    Dimensions in. [mm] TV INTERFACE FRONT VIEW 43.31 [1100.0] FOR SMALL PARTS PANEL 7.87 [200.0] MAX WALL PLATE 52.93 [1344.5] 33.43 [849.1] MIN WALL PLATE 31.50 [800.0] 16.73 TILT RANGE [425.0] 10° WALL PLATE 24.00 ]609.6[ 23.62 [600.0] 17.72 [450.0] 16.00 ESTIMATED 55"...

  • Page 24: Ne Pas Dépasser

    Poids limite (avec les accessoires) Si votre téléviseur (avec les accessoires) pèse plus, Ce support 136 kg n’est PAS compatible. Visitez SANUS.com ou composez le NE PAS DÉPASSER (300 lb) 1-800-359-5520 pour trouver un support compatible. La construcción de su pared montants en bois Béton coulé...

  • Page 25: Avant De Commencer

    Avant de commencer Retirez le socle de votre téléviseur ... s'il est installé bien sûr. Installez tout accessoire que vous prévoyez d’ajouter à votre téléviseur . Vérifiez les manuels d’installation de tous les accessoires pour savoir si vous devez les INSTALLER AVANT de monter votre téléviseur. Protégez la face de votre téléviseur lorsque vous la poserez vers le bas pour l’installation.
  • Page 26 , puis à au moins 406 mm (16 po) du centre, pour un minimum de 6 tire-fonds au total. POSITIONNEZ LE GABARIT CONSEIL : Pour calculer l'emplacement précis de la plaque murale, renseignez-vous sur notre HeightFinder sur le site sanus.com [www.san.us/3276]. PERCEZ SERREZ CORRECTEMENT ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! Les quatre boulons tire-fond...
  • Page 27 ÉTAPE 3 Fixation du téléviseur sur la plaque murale PAGE 18 ACCROCHEZ LOURD ! Vous aurez besoin de quelqu'un pour vous aider à cette étape. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! Pour les utilisations sur béton, les pattes de fixation pour téléviseur doivent rester centrées sur la plaque murale Pour les plaques murales étendues : Les pattes de fixation pour téléviseur...
  • Page 28 ©2025 Legrand AV Inc. All rights reserved. SANUS Elite is a brand of Legrand. SANUS Elite, HeightFinder and the Elite logo are registered trademarks of Legrand. ©2025 Legrand AV Inc. Tous droits réservés. SANUS Elite est une marque de Legrand. SANUS Elite, HeightFinder et le logo Elite sont des marques déposées de Legrand.
