ISAAC 58
INSTALLATION MANUAL | MANUEL D'INSTALLATION | MANUAL DE INSTALACIÓN
An installation video guide can be found on our Youtube channel:
Un guide d'installation video est disponible sur notre chaîne Youtube:
Una guía de instalación de vídeo está disponible en nuestro canal de Youtube:
https://tinyurl.com/2t7vxrf3
Questions, problems, need help?
Call our customer service department at
1-866-839-2888, 8 a.m. - 5 p.m., EST, Monday - Friday
Questions, problèmes ou besoin d'aide?
Contactez notre service à la clientèle au
1-866-839-2888, du lundi au vendredi de 8h00 à 17h00 HNE.
Preguntas, problemas o necesita ayuda?
Llame a nuestro departamento de servicio al cliente al
1-866-839-2888, 8 am. – 5 pm., HDE, Lunes a Viernes.
P. 1
www.ovedecors.com | customerservice@ovedecors.com
Publicité
Manuels Connexes pour OVE ISAAC 58
Sommaire des Matières pour OVE ISAAC 58
- Page 1 ISAAC 58 INSTALLATION MANUAL | MANUEL D’INSTALLATION | MANUAL DE INSTALACIÓN An installation video guide can be found on our Youtube channel: Un guide d’installation video est disponible sur notre chaîne Youtube: Una guía de instalación de vídeo está disponible en nuestro canal de Youtube: https://tinyurl.com/2t7vxrf3...
- Page 2 SPECIFICATION SPÉCIFICATIONS ESPECIFICACIONES 11” [280] Drain / Drenaje 2” [50] 39 3/8” [1000] 57 1/16” [1450] 58 1/4” [1480] 51.2gal 68.3lbs 0.194m 31kg Measures: inch [millimeter] Mesures: pouce [millimètre] Medidas: pulgadas [milímetros] P. 2...
- Page 3 FLOOR TRACING TEMPLATE GUIDE DE TRAÇAGE GUÍA DE SEGUIMIENTO Drain Floor cut-out for P-trap Rough-in zone for waste pipe Drain Ouverture dans le plancher pour p-trap Zone indiquée pour tuyau d’évacuation Drenaje Abertura en el piso de p-trampa Zona para la tubería de desagüe 20 7/16”...
- Page 4 PART LIST LISTE DES PIÈCES LISTA DE PIEZAS PART # DESCRIPTION QUANTITY CODE # DE PIÈCE DESCRIPTION QUANTITÉ CODE PARTE # DESCRIPCIÓN CANTIDAD CÓDIO 1-1/2 NPSM to SCH40 Pipe Adapter Raccord 1-1/2 NPSM à Tuyau SCH40 Adaptador 1-1/2 NPSM à SCH40 Tubo TOOLS REQUIRED OUTILS REQUIS HERRAMIENTAS NECESARIAS...
- Page 5 CAUTION ATTENTION ATENCIÓN You will need at least two people to install this product properly. In order to reduce the risks of personal injuries, do not support or lift the bathtub by the rim. Provide adequate support under the feet. The distributor is not responsible for any damage to the unit or personal property caused by improper installation.
- Page 6 FLOOR TRACING TRAÇAGE SEGUIMIENTO 1.1. Place the bathtub in the desired position on the floor, manually locate the proper position for your plumbing and trace the outline on the floor. 1.2. Place the tub in the desired position and level it using the adjustable feet. 1.3.
- Page 7 INSTALLATION: USING REGULAR PVC PIPING INSTALLATION: UTILISATION DE TUYAU PVC RÉGULIER INSTALACIÓN: USO DE TUBERÍAS DE PVC REGULARES THIS IS THE INSTALLATION METHOD RECOMMENDED BY THE MANUFACTURER. 2.1. Apply Teflon Tape and/or thread sealant to the pre-installed bathtub drain. 2.2. Screw the provided 1-1/2 NPSM to SCH40 Pipe Adapter to the drain. Cut a 1-1/2 PVC Extension Tube to the desired length. Then connect it to the Adapter using PVC pipe sealant to join the parts together.
- Page 8 SEALING SCELLAGE SELLADO BEFORE FIXING YOUR TUB TO THE FLOOR, ENSURE THAT YOU HAVE INSTALLED YOUR FAUCET (if applicable) AND THAT YOU HAVE CHECKED FOR LEAKS. 3.1. Test for leak by filling up the tub and let it drain. Then check all plumbing connections for leaks. Ensure the tub is leveled prior to sealing. 3.2.
- Page 9 MAINTENANCE AND CARE ENTRETIEN ET MAINTENANCE MANTENIMIENTO Y CUIDADOS MAINTENANCE AND CARE DO NOT USE ANY TYPE OF DRAIN SNAKE OR DRAIN CLEANER IF YOU HAVE INSTALLED THE PROVIDED FLEXIBLE PIPE. The DISTRIBUTOR shall not be responsible or liable for any plumbing failure or damage caused by the use of drain snake or drain cleaners.
- Page 10 CONSUMER RESPONSIBILITIES The DISTRIBUTOR’s products will remain beautiful for many years if properly cared for. The DISTRIBUTOR does not recommend the use of harsh abrasive cleansers on any of its products. Harsh cleansers will damage the finish of your product. LIMITED 25 YEARS WARRANTY This warranty extends only to the original owner/user for personal household use only.
