SOLAR-KPB

Dual-Tech Digicode/Proximity

Reader - Wiegand

The SOLAR-KP from CDVI is a standard proximity

card reader including a keypad.

These stylish new readers are available in black.

The SOLAR-KP gives an anytime status of the

door through multi-coloured LED's.

These access control readers have a high

performance read range and are easy to mount.

We, CDVI, declare that the SOLAR radio equipment complies

with directive 2014/53/UE. The full text of the EU declaration is

available at www.cdvi.com

• Proximity reader and/or Digicode keypad

• Wiegand 26, 30 or 44-bit

• Sensitive touch keypad

• Visual and audible feedback

• Technology: 125 kHz

• Power requirements: 12V DC

• Current consumption: 150 mA

RFID Frequency band: 125 kHz. Maximum transmitted power below the allowed limit: <60dBμA/m

QUICK START

INSTALLATION GUIDE

w w w . c d v i g r o u p . c o m

RED Certification

Certification CE

Vibrations

-25°C à +70°C

IK10

IP53

DEEE

SOLAR-KPB

YEAR

WARRANTY

Page 1 These access control readers have a high performance read range and are easy to mount. DEEE We, CDVI, declare that the SOLAR radio equipment complies with directive 2014/53/UE. The full text of the EU declaration is available at www.cdvi.com SOLAR-KPB •...
Page 2 - LEDs activated with 0V input. Standard Mode - Badge recognized: the orange LED illuminates and the beeper emits a tone during 150 milliseconds CDVI SAS 31 avenue du Général de Gaulle 93500 PANTIN 01 48 91 01 02 w w w . c d v i g r o u p . c o m...
Page 3 Lecteur double technologie Proximité/Digicode - Wiegand GARANTIE YEAR WARRANTY RED Certification Certification CE Le SOLAR-KP de CDVI est un lecteur de cartes de GARANTIE Vibrations proximité standard incluant un clavier. YEAR -25°C à +70°C WARRANTY Ces nouveaux lecteurs élégants sont disponibles en noir.
Page 4 - Activation voyants par niveau 0 V. Mode standard - Badge lu : voyant orange et bip pendant 0,15 seconde puis retour suivant état activation en cours. CDVI SAS 31 avenue du Général de Gaulle 93500 PANTIN 01 48 91 01 02...
