Specification:
Specifications are subject to change without notice.
Application:
The jacks are suitable only for vertical lifting jobs. The range of ambient
temperature at which the jacks can be used from is -20 °C to 55 °C. They
should not be used in places where 9 acid, alkali or other corrosive gases
exists. They are widely used in automobiles and tractors.
Safety Instructions:
* Never exceed the jack's rated load capacity.
* Base of jack should always rest on a firm level surface.
* Never work under the lift load without additional support means.
* The contact between the top and the lifted body must be perfect.
* When several jacks are used together, the raising speed should be
coincident with each other.
* Secure the vehicle against running away.
* The adjustment of the pressure relief valve is set by factory. The user do not
adjust it.
Operating Instruction
To Raise:
* Turn the delivery valve clockwise until it is firmly closed before pumping.
* Position the jack under the load and turn the extension saddle until solid
contact with the load to be lifted.
* Operate the jack handle until the saddle contacts the load. Once again
check to see that saddle is correctly positioned.
* Raise the load to the desired height and then transfer load to the vehicle
support stands.
CAPACITY
MIN.H
(TON)
(MM)
2
158
3
180
4
180
5
200
6
200
8
200
10
200
12
210
15
220
16
220
20
235
30
255
32
255
50
260
3
LIFTING.H
ADJUST.H
(MM)
(MM)
90
50
110
50
110
50
125
60
125
60
125
60
125
60
125
60
135
60
135
60
145
60
150
/
150
/
260
/
MAX.H
N.W
(MM)
(KGS)
2.3
298
2.9
340
2.9
340
3.8
385
3.8
385
4.6
385
5.1
385
6.7
395
6.9
415
6.9
415
9.3
440
12.5
405
12.5
405
26.5
520
