3.
Adjust the height-adjustment bar to the desired level and then lock it with the fixing nut.
4.
Loosen the fastening nut and introduce the height-adjustment bar through the head's
lower part hole and then screw the fastening nut.
5.
To attach the front grill to the back grill, use the grill ring carefully to hold them together and
fasten the grill ring with the screw provided.
Before using the fan make sure that it is on a flat and stable surface. Damage may occur if it is
placed on an uneven surface.
3. OPERATION
Set all the switches to the OFF position, then insert the plug directly into a standard AC socket-
outlet. Make sure the plug fits tightly into outlet.
1.
Rotate the timer knob counter-clockwise and select ON, press the button speed to start the
fan and select the fan speed level: 1 (Low), 2(medium), 3I(high). To stop the fan, just press
the button "0".
2.
Set the time by rotating the timer knob clockwise to select a desired operating time, it can
be programmed 0-60 minutes.
3.
For a greater air flow, press the head-movement button to activate the oscillation function.
To deactivate it, pull from the same button. The air flow's angle can be adjusted by turning
up or down the fan.
4.
To lift or lower the height of the fan, loosen the lower locknut, and lift or lower the lift pole
to your desired height, then fasten the lower locknut tightly.
Note: turn the fan off before adjusting its height.
•
To completely shut the fan off, turn all the controls to OFF, and remove plug from the
socket-outlet.
4. CLEANING AND MAINTENANCE
1.
Always remove the plug from the socket-outlet and allow the fan to stop operating before
clean it.
2.
Clean the external surfaces of the fan with a soft damp (not dripping wet) cloth.
WARNING:
•
Do not immerse the fan in water.
•
Do not use any cleaning chemicals such as detergents and abrasives.
•
Do not allow the interior (special for the PCB) to get wet as this could create a hazard.
3.
When the unit is not in use, make sure that it is unplugged from the wall socket. To store the
fan, you may pack it in the original carton and store it in a cool and dry place until later use.
4.
In case of malfunction or doubt, do not try to repair the fan yourself, it may result in a fire
hazard or electric shock.
FORCESILENCE 1010/1020 EXTREMEFLOW
ENGLISH
15
