Uline H-9855 Mode D'emploi

H-9855
12' RECTANGLE
TABLE WITH STOOLS
TOOLS NEEDED
Drill Ratchet with
(optional) 3/8" Socket
• This table should be assembled only by authorized
adults who have read and understood these
instructions.
• Movement and/or operation of these tables by
children could result in serious injury.
• It is dangerous to leave children unattended in the
area of folded tables.
• Do not use tables as room dividers.
• To avoid table tipping over, push from end of table;
do not push from flat table side.
• Do not stand on stools.
LATCH ASSEMBLY
1. Remove the plastic washer and locknut from bolt on
underside of table. (See Figure 1)
2. Install the latch and replace the washer and locknut.
(See Figure 1)
NOTE: Ensure latch moves up and down freely.
PAGE 1 OF 12
1-800-295-5510
uline.com
PARTS
Stool x 12
SAFETY
ASSEMBLY
Pour le français, consulter les pages 9-12.
Bolt x 48
• Do not sit or stand on tabletop.
• Legs contain torsion bars under rotational force
that can be hazardous and could result in
serious injury if released without following proper
procedures.
• Center legs contain springs under compression
that may be hazardous and could result in
serious injury if released without following proper
procedures.
• If replacement or repair of leg assemblies is
required, contact Uline Customer Service at
1-800-295-5510.
Latch
Figure 1
Para Español, vea páginas 5-8.
Washer
Locknut
1123 IH-9855
