The shoulder straps of the car seat are placed in such a way that your child is
comfortable, but TIGHT around your child.
•
The shoulder straps are adjusted correctly.
•
The shoulder straps are not twisted.
•
The connecting parts are engaged in the buckle of the safety belt.
ADJUSTABLE LINEAR SIDE-IMPACT PROTECTION - ILLUSTRATION C.5:
Adjustable Linear Side-impact Protection (L.S.P.) is a system for absorbing the force of
an impact in the event of an accident. The force of the side impact is systematically
absorbed by the individually adjustable side protectors. In order to achieve the best
possible protective effect, unfold the system (18) as far as possible towards the vehicle
door closest of the car seat. To release the L.S.P push the marked area (19) on the
L.S.P. Ensure that the extendable part locks in place with an audible "CLICK". If it is not
possible to completely unfold the L.S.P with a closed vehicle door, you may as well use
the infant car seat with a closed protectors. The side protrectors can be completely
folded back into initial position if you pull on the marked area (press 19 first, then press
18). NOTE: When using the car seat on a middle position in the vehicle, it is prohibited
to fold out the (L.S.P.) device.
BACKREST RECLINE ADJUSTMENT - ILLUSTRATION C.6:
WARNING! The infant car seat must ONLY be reclined outside of the vehicle.
The car seat can be put into reclining position by pulling the release button (21) at the
same time as pushing the back section down. Ensure that the seat has been correctly
locked in place in the reclining position. The position is permitted exclusively for use
outside of the vehicle, for example on a stroller, and must not be used ina vehicle
under any circumstances.
NOTE: Do not undertake any adjustments to the seat setup while the vehicle is in
motion.
CHILD SEAT INSTALLATION IN REARWARD FACING POSITION - FIGURE D
Place the car seat with the front part opposite to the direction of movement (the baby
must be in the direction opposite to the direction of movement). Tip! In some cases,
it is possible for the car seat not to be placed properly or to be tilted too much on the
car seat. This can be adjusted by placing a blanket under the car seat or selecting
another position for placing.
In order to secure the car seat, use the 3-point safety belt of your car as follows:
Make sure that the handle is in its uppermost position А. Pull the vehicle safety belt
and place it through the child's car seat.
Connect the tongue of the belt with the buckle of the car seat and lock the safety belt.
Place the waist belt in the blue guides on both sides of the car seat. Warning! Do not
twist the belt. Tighten the waist belt by pulling the diagonal belt.
CHILD'S HEIGHT: 40-87 cm
25
