AOC GAMING 24G4XE Manuel De L'utilisateur

Find your product and get support
FAQ Driver User
Manual
Россия
Europe
https://aoc.com/uk/support https://aoc.com/ru/support
Australia
Hong Kong S.A.R.
https://au.aoc.com/user_manual https://hk.aoc.com/user_manual
中國台灣
Indonesia
https://tw.aoc.com/user_manual https://id.aoc.com/user_manual
日本 한국
https://jp.aoc.com/user_manual https://kr.aoc.com/user_manual
Malaysia Myanmar
https://my.aoc.com/user_manual
https://mm.aoc.com/user_manual
New Zealand
Philippines
https://nz.aoc.com/user_manual
https://ph.aoc.com/user_manual
1
3
1
2
ประเทศไทย
Singapore
https://th.aoc.com/user_manual
https://sg.aoc.com/user_manual
Việt Nam
Middle East
https://vn.aoc.com/user_manual https://me.aoc.com/user_manual
South Africa Brasil
https://za.aoc.com/user_manual https://aoc.portaltpv.com.br/
India
US
https://aoc.com/in-en/support
https://aoc.com/us/support
Canada
https://aoc.com/ca-en/support
®
Product information for EU/UK Energy
H41G24M1615A92
2
100mm
100mm M4
X4 Wall Mounting: M4*(10+X)mm
(X=Thickness of Wall mount bracket)
M=4.0Max
M4-P0.7
Dk=8.0 H=2.0 L=10+X
HDMI1 HDMI2
Q U I C K S TA R T G U I D E
24G4XE
A O C G A M I N G M O N I TO R
W W W . A O C . C O M
©2024 AOC. All rights reserved
3
RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE
1920x1080 60 HZ Off 50 80 DP
Gaming Mode 80
Game Setting
Shadow Control
Game Color
Settings
Adaptive-Sync
Audio
Dial Point
OSD Setup
Shadow Boost
Information
MBR
MBR Sync
HDMI1
HDMI2
DP
Gaming Mode
Off
Monitor Stand Base
Quick Start Guide Warranty Card Power Cable
HDMI Cable DP Cable
*Different according to countries/regions
Display design may differ from that illustrated
4
General Specification
Model Name 24G4XE
Driving System TFT Color LCD
Panel
Viewable Image Size 60.5cm Diagonal (23.8'' Wide Screen)
Pixel Pitch 0.2745mm(H)x0.2745mm(V)
Horizontal Scan
30k~200kHz
Range
Horizontal Scan
527.04mm
Size(Maximum)
Vertical Scan Range 48~180Hz
Vertical Scan
296.46mm
Size(Maximum)
Max Resolution
1920x1080@180Hz
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Others
Typical(Default Brightness
37W
And Contrast)
Max. (Brightness =
≤ 21W
Power Consumption
100, Contrast =100)
≤ 0.3W
Standby Mode
Dimensions(with
540.0x434.5x177.39mm (WxHxD)
stand)
Net Weight 3.48kg
Connector Type HDMIx2/DP/Earphone Out
Physical
Characteristics
Signal Cable Type Detachable
0°C~40°C
Operating
Temperature
Non-Operating -25°C~55°C
Operating 10%~85% (Non-Condensing)
Environmental
Humidity
Non-Operating 5%~93% (Non-Condensing)
Operating
0m~5000m (0ft~16404ft)
Altitude
Non-Operating 0m~12192m (0ft~40000ft)
