ECS Electronics VW-146-D1 Instructions De Montage page 25

INFO
Golf VII/ Golf GTE/ Golf Variant Alltrack/ Passat/ Touran II/ Arteon/ T-Roc
50
51
2
20 Amp.
Pos. 38
+30
© ECS Electronics B.V.
L5
15 Amp. 15 Amp.
Pos. 28 Pos. 48
+15
+30
All models
OG
is for +30 Module
RD
is for +30 Trailer
YE
is for +15 Trailer
1
YE
+15
Pos.48
If pos. 48 is taken, choose free pos.
+30
+30
+15
L5
OG
+30
Pos.38
Page 25 VW-146-D1 / 120225NN
RD
+30
Pos. 28
