FLANGE PRESSURE REGULATOR MADE OF STAINLESS STEEL THROUGHOUT
Description
Pressure regulator made of stainless steel throughout. Even when spindle is unscrewed the
indicated minimum outlet pressure is existent. Inner parts are replaceable.
With stainless-steel dirt-trap / strainer
Medium
aggressive liquids, compressed air or non-corrosive gases. Not suitable for steam!
Supply pressure
see chart, max. 40 bar
Minimum press. difference P
: P
= 1 bar
1
2
Adjustment
with hexagon socket, with locknut
Relieving function
non-relieving
Gauge port
G1/4 on both sides of the body, one screw plug supplied
Mounting position
any, preferably vertical
Flange
according DIN 1092, overall length according DIN 558-1
Temperature range
0 °C to 190 °C / 32 °F to 374 °F for FKM for media and ambient temperature
0 °C to 130 °C / 32 °F to 266 °F for EPDM for media and ambient temperature
Material
Body, spring cage, inner valve:
Elastomer and seals:
Dimensions
K
-
Flow rate
v
A
B
C
value
water
mm mm
mm
(m
/h)*
l/min*
3
1
Regulator with flange
200 269 150
9.0
150
219
219
219
247
230 269 165
13
216
219
219
219
247
Special options,
add the appropriate letter
EPDM Elastomer
membrane and seals, FDA approval
Accessories,
enclosed
SST pressure gauge
Ø 50 mm, 0...*
Ø 63 mm, 0...*
RAF
*
1
at 2 m/s water speed
*
3
02 = 0...2 bar, 04 = 0...4 bar, 06 = 0...6 bar, 10 = 0...10 bar, 16 = 0...16 bar, 25 = 0...25 bar
stainless steel 1.4408 / V4A / 316 L
FKM / FPM, optionally EPDM
Supply
Mounting
pressure
flange
max. bar
DN
2
for liquids, supply pressure max. 25/40 bar
non-relieving, 1.4408 / V4A / 316L, FKM
25
DN40
25
25
25
40
25
DN50
25
25
25
40
bar, G1/4, for DN 15
3
3
bar, G1/4, and all the rest of them
RAF
*
2
for compressed air the flow is 70 times greater
Pressure
Order
Price
range
number
C
bar
€
RAF
RAF-12A
0.2 ... 2
1.570,00
0.5 ... 4
RAF-12B
1.570,00
1.5 ... 6
RAF-12C
1.570,00
1.5 ... 10
RAF-12D
1.570,00
RAF-12F
2.0 ... 20
1.620,00
RAF-16A
0.2 ... 2
1.760,00
0.5 ... 4
RAF-16B
1.760,00
1.5 ... 6
RAF-16C
1.760,00
1.5 ... 10
RAF-16D
1.760,00
RAF-16F
2.0 ... 20
1.820,00
RAF-. . .TD
o. request
B
MS5002-..*
90,00
3
MS6302-..*
3
96,00
RAF
DN 15 up to DN 50
liquids or gases
RAF-12/-16A
RAF-12/-16B/C/D
RAF-12/-16F
Product group
Order example:
RAF-12A
Special
9
9.11
