MINIATURE PRECISION PRESSURE REGULATOR
Description
Compact, high-precision, diaphragm-operated pressure regulator for panel-mounting.
Media
non-corrosive gases, filtered, lubricated or unlubricated compressed air
Supply pressure
max. 17 bar
Air consumption
ca 1.5 l/min at 7 bar supply pressure
Adjustment
by handwheel with locknut
Relieving function
relieving
Gauge port
RT-M5: gauge port M5
Mounting position:
any
Temperature range
0 °C to 70 °C / 32 °F to 158 °F, for appropriately conditioned compressed air down to -30 °C / -22 °F
Material
Body:
anodized aluminium
Elastomer:
FKM
Inner valve: stainless steel and brass
Dimensions
Flow
A
B
C
rate
mm
mm
mm
l/min*
1
Pressure regulator M5
25
83
14.5
100
Regulator with flange
25
83
–
100
Special options,
add the appropriate letter
side connection
M5 or o-ring
/
˝ NPT
ports with female threads
1
16
Accessories,
enclosed
mounting bracket
made of steel, mounting nut at the device
A
B
RT-M5
*
1
for compressed air: 7 bar supply pressure, 6 bar outlet pressure and 1 bar pressure drop
RT-MF: not available
Supply
Connection
Pressure
pressure
thread
max. bar
M5 / Flansch
supply pressure max. 17 bar, with constant bleed
17
M5
supply pressure max. 17 bar, with constant bleed
17
flange
8
15
gauge port
M5
P
P
2
1
C
M5 connection
in base
RT-M5
Order
range
number
C
bar
RT
RT-M5A
0 ... 0.35
0 ... 1.1
RT-M5B
RT-M5C
0 ... 2.1
0 ... 4.2
RT-M5D
RT-M5E
0 ... 7.0
RT
0 ... 0.35
RT-MFA
0 ... 1.1
RT-MFB
0 ... 2.1
RT-MFC
0 ... 4.2
RT-MFD
0 ... 7.0
RT-MFE
RT-M . .X14
RT-M . .X61
BW10-01
26
26
4.5
BW10-01
inlet
outlet
10-32 UNF
flange
connection
RT-MF
M5 or flangeable
0 ... 350 mbar / 7 bar
0
RT-M5C
with mounting nut
0
t
RT-MFC
with flange and mounting nut
M5
cross section
Product group
Produktgruppe
Order example:
RT-M5A
RT
Miniatur
1
flange
1.19
