PRECISION PRESSURE REGULATOR FOR FLOW 30 000 L/MIN
Description
Provides precision regulation in high flow and high relief applications. A sensitive rolling diaphragm and
balanced inner valve assure constant outlet pressure even with supply pressure and flow fluctuations.
Media
compressed air or non-corrosive gases
Supply pressure
max. 18 bar, optionally max. 35 bar
Accuracy
response sensitivity: < 2 mbar
Air consumption
0.5% of volume flow, max. 15 l/min
Adjustment
by T-handle with locknut
Relieving function
relieving, optionally non-relieving
Relief capacity
1 200 l/min at 1.5 bar outlet and 0.35 bar overpressure above setpoint
Gauge port
G1/4 for outlet pressure
Temperature range
0 °C to 90 °C / 32 °F to 194 °F, for appropriately conditioned compressed air down to -40 °C / -40 °F
Material
Body:
Elastomer: NBR/Buna-N, optionally FKM at 35 bar version
Inner valve: stainless steel, brass, aluminium and steel
Dimensions
A
B
C
value
mm
mm
mm
(m
Precision pressure regulator
141
287
56
141
287
56
Präzis.
5
Special options,
NPT
non-relieving
tapped exhaust
supply pressure 35 bar free of non-ferrous metal, FKM elastomer
tamper-proof cap
Accessories,
enclosed
pressure gauge
mounting bracket
B
R102
*
1
at 10 bar supply pressure and 2.8 bar outlet pressure
*
2
01 = 0...1 bar, 02 = 0...2.5 bar, 04 = 0...4 bar, 10 = 0...10 bar
Gauges: see chapter for measuring devices
5.16
5.16
aluminium die-cast
K
-
Flow
Connection
v
rate
thread
/h)
m
/h*
l/min*
³
³
1
1
supply pressure max. 18 bar, relieving,
with constant bleed
11.4
1 680 28 000
12.2
1 800 30 000
G11/2
add the appropriate letter
connection thread
and without constant bleed
G
/
connection thread
3
8
aluminium, adjustment by screwdriver, total height 295 mm
Ø 63 mm, 0...*
2
bar, G1/4
made of steel
A
gauge
G1/4
C
Mounting position any
Pressure
Order
range
number
G
bar
R102
R102-081
G1
0.001 ... 0.7
R102-08A
0.03 ... 2.0
0.07 ... 4.0
R102-08B
0.14 ... 7.0
R102-08C
0.14 ... 10
R102-08D
0.001 ... 0.7
R102-121
0.03 ... 2.0
R102-12A
0.07 ... 4.0
R102-12B
0.14 ... 7.0
R102-12C
R102-12D
0.14 ... 10
R102- . . . N
R102- . . . K
R102- . . . X12
R102- . . . X62
R102- . . . T
MA6302-..*
BW00-30
Ø 7
64
19
63
BW00-30
G1 and G11/2
30 000 l/min
Price
D
€
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
1.745,00
R102
+10,00
+90,00
+620,00
+620,00
+100,00
B
inlet
2
11,00
150,00
cross-section
Product group
Order example:
R102-081
R102
outlet
