PRECISION PRESSURE REGULATOR WITHOUT CONSTANT BLEED
Description
Regulator provides precision regulation in high flow and high relief applications.
Media
compressed air or non-corrosive gases
Supply pressure
max. 18 bar
Accuracy
at supply pressure variation of 7 bar: < 7 mbar pressure deviation
response sensitivity:
Air consumption
without constant bleed
Adjustment
by handwheel with locknut
Relieving function
relieving
Relief capacity
200 l/min at 1.5 bar outlet and 0.35 bar overpressure above setpoint
Gauge port
G1/4 on both sides of the body, screw plugs supplied
Temperature range
0 °C to 80 °C / 32 °F to 194 °F, for appropriately conditioned compressed air down to -40 °C / -40 °F
Material
Body: zinc die-cast
Dimensions
K
-
v
A
B
C
value
mm
mm
mm
(m
/h)
m
³
Precision pressure regulator
54
129
25
0.73
54
129
25
0.78
Special options,
add the appropriate letter
NPT
connection thread
tamper-proof cap
aluminium, adjustment by screwdriver, total height 139 mm
Accessories,
enclosed
pressure gauge
Ø 50 mm, 0 ...*
mounting bracket
made of steel, including mounting screws
A
B
R100
*
1
at 7 bar supply pressure and 1.4 bar outlet pressure
*
2
01 = 0...1 bar, 02 = 0...2.5 bar, 04 = 0...4 bar, 10 = 0...10 bar
Gauges: see chapter for measuring devices
< 2 mbar
Inner valve: aluminium, brass and neoprene
Flow
Connection
rate
thread
/h*
l/min*
G
³
1
1
supply pressure max. 18 bar, relieving,
without constant bleed
78
1 300
G1/4
84
1 400
G
⁄
3
8
bar, G1/4
2
19
10
gauge
G1/4
33
C
50
BW20-04
Mounting position any
Elastomer: NBR/Buna-N
Pressure
Order
Price
range
number
D
bar
€
R100
R100-021
0.03 ... 0.7
424,00
R100-02A
0.03 ... 2.0
424,00
0.07 ... 4.0
R100-02B
424,00
0.14 ... 10
R100-02C
424,00
0.03 ... 0.7
R100-031
424,00
0.03 ... 2.0
R100-03A
424,00
0.07 ... 4.0
R100-03B
424,00
0.14 ... 10
R100-03C
424,00
R100-0 . . N
+10,00
R100-0 . . T
+37,00
B
MA5002- . . *
10,00
2
BW20-04
16,00
R100
G1/4 and G
⁄
3
8
1 400 l/min
R100
outlet
inlet
cross-section
Product group
Order example:
R100-021
Präzis.
5
5.09
