Electronical consideration
CONTACT ARRANGEMENT
The EFFI-SHARP-CPT is supplied with a direct current through the connector
intensity which flows through the LED and on the LED version.
M8 connector – direct control (expert mode)
Pin
Cable
Contact arrangement
number
color
1
White
2
Brown
3
Green
4
Yellow
5
Grey
6
Pink
7
Blue
M8 Male 8 contacts
8
Red
LED arrangement
MX1
STROBE CONTROL
You can see below 5 possible configurations depending on the current that you provide to the EFFI-SHARP-CPT.
Configuration
Current
1
1.2A
2
1.5A
3
2A
4
2.5A
5
3.5A
All manuals and user guides at all-guides.com
High power shape projector
With MX1
-V
LED
+V
LED
N.C
N.C
N.C
N.C
-TH
Thermistor
+TH
Thermistor
MX2
Max pulse duration (µs) / τ
pulse
50000
10000
1000
100
40
Mini Parc du Verger – Bâtiment E
1 Rue de Terre Neuve
91940 LES ULIS, FRANCE
M8 Male 8 contacts
. The power consumption depends on the
With MX2
-V
n°1 (Z2)
LED
+V
n°1 (Z2)
LED
-V
n°2 (Z1)
LED
+V
n°2 (Z1)
LED
N.C
N.C
-TH
Thermistor
+TH
Thermistor
Electrical diagram for each channel :
Protective diode D TVS 400mW 24V :
PTVS24VS1UR
Thermistor NTC 10kΩ TH1 :
VISHAY NTCS0805E3103JMT
D
0.5
0.1
0.01
0.001
0.0004
Tel: +33 9 72 38 17 80
Fax: +33 9 72 11 21 69
Email: contact@effilux.fr
USER'S GUIDE EFFI-SHARP-V2
Version 2.1.2020
Last update: June 17, 2020
Page 3 / 4
