This version of the M-3
was but one of the many
variants of this versatile
vehicle. These half-tracked
machines were highly re-
garded for their excellent
off- road capabilities, and
proved to be high mobile
mounts for versions fitted
with field guns or Howit-
zers. The M-3 had a top
speed of 45 mph and
weighed nearly 10 tons!
Your Revell model comes
with a ultility trailer, two
figure and authentic stick-
er decals, movable can-
non and rolling wheels.
* APPLY STICKER
* APPLIQUEZ LES AUTO-COLLANTS
READ BEFORE YOU BEGIN
• CLEAR A SPACE TO WORK ON
• STUDY THE ASSEMBLY DRAWINGS
BEFORE YOU BEGIN
• EACH PLASTIC PART IS IDENTIFIED BY
A PART NUMBER
• DO NOT OVER TIGHTEN SCREWS
• SEE NOTE ABOUT APPLYING
STICKERS IN STEP #8
CAUTION:
POSITION ALL PARTS IN THIS KIT
CAREFULLY. PARTS WILL ONLY SNAP
TOGETHER ONCE.
If you have any questions or comments, call our hotline at:
Revell Inc Consumer Service Department, 1840 Howard Street Unit A, Elk Grove Village, Illinois 60007
Be sure to include the plan number (85174410200), part number, description, your return address and phone number.
KIT 1744
U.S. ARMY HALF-TRACK
* REPEAT SEVERAL TIMES
* A REPETER PLUSIEURS FOIS
or, please write to:
Visit our website: www.revell.com
Revell Inc Elk Grove Village, IL. Copyright © 2009. All rights reserved.
Á LIRE AVANT DE COMMENCER
• DÉGAGGEZ UN ESPACE POUR
TRAVAILLER.
• ÉTUDIEZ LES ÉTAPES DE MONTAGE
AVANT DE COMMENCER.
• CHAQUE PIÉCE EN PLASTIQUE PORTE
UN NUMÉRO DE PIÉCE.
• NE SERREZ PAS TROP LES VIS.
• LISEZ LA RE MARQUE CONCERNANT
L´APPLICATION DES AUTO-COLLANTS,
´A L´ ÉTAPE 8.
MISE EN GARDE:
POSITIONNEZ AVEC PRÉCAUTION
TOUTES LES PIÉCES DE CE MODÉLE
RÉDUIT, CAR VOUS NE POUVEZLES
EMBOîTER QU'UNE SEULE FOIS.
(800) 833-3570
85174410200
* REMOVE AND THROW AWAY
* A RETIRER ET JETER
