Model
4801.400
4801.600
4801.800
4801.1000
Installation Dimensions (mm)
Model
4801.400
4801.600
4801.800
4801.1000
Installation Procedure
◆ Note the following two points during installation:
Installation Space.(Units:mm)
Applicable Drawer
Length (inch)
Size (mm)
Travel
L1
L2
400
900
600
1450
800
1850
1000 2250
16
24
32
40
(mm)
A
500
142.5
850
161.7
1052
171.3
1250
177
- 3 -
Sliding Length
(mm)
500
850
1050
1250
Hole Pattern (mm)
B
C
285
/
323.4 485
342.6 514
354
531
Max. Load
(lbs / kg)
255 / 115.8
245 / 111.3
230 / 104.5
215 / 97.6
D
E
/
/
/
/
685
/
708
885
