Ensure that all components listed in
Component
Ceiling bracket
Screw, sheet metal
1. Remove all sheet metal screws that secure front and rear of cabinet top.
2. Align ceiling brackets with screw holes in front and rear of cabinet top and secure brackets to heater using screws
from kit.
3. While supporting heater bottom with plywood or other suitable material, lift heater into place using suitable lift or
assistance and secure ceiling brackets to ceiling using field-supplied hardware.
Specifications and illustrations subject to change without notice or incurring obligations.
Latest version of this manual is available at www.reznorhvac.com.
©2025 Reznor LLC, O'Fallon, MO. All rights reserved.
OPT-CK22 (02-25) 1037006-C
KIT COMPONENTS
Table 1
are available before beginning installation.
Table 1. Kit Components
EUH
1042759
1042700 (2)
195638 (13)
INSTALLATION
Model
Kit PN
Component PN (Quantity)
UDX, UDXC, UDZ
1036357
1034211 (2)
195638 (10)
