HARDWARE CONTENTS (shown actual size)
AA
BB CC DD EE
M6 Flange Nut M8 Nut Spring Washer D8 Large Washer
(Preassembled (Preassembled (Preassembled
(Preassembled
M6 Ring Screw
to Base Support to Base Support to Base Support
to M6 Ring
(FF)) (FF)) (FF))
Screw (AA))
Qty. 1 Qty. 1 Qty. 3 Qty. 3 Qty. 3
FF GG HH II
Base Support
D8 Washer
Handle R-Pin
(Preassembled to
(Preassembled (Preassembled (Preassembled
Pedestal Base (G))
to Fire Bowl (D)) to Handle (GG)) to Handle (GG))
(Not To Scale)
Qty. 1 Qty. 2 Qty. 4 Qty. 4
