Guardian HALO Manuel D'instructions page 7

English
Diagram A - Fall Clearance
 CAUTION! Fall clearance
calculation shown below is
based on a standing worker
falling directly in-line with
anchor point.
 SAMPLE CALCULATION ONLY.
Always refer to connector
instructions for product-
specific clearance
information.
Maximum Arrest

Distance/
Deceleration:
100-310 lb: 3'
(59-140 kg: 0,9 m)
311-420 lb: 3.5'
(141-190 kg: 1,07 m)
Deceleration
■
Harness Stretch
■
Safety Factor
■
Swing Fall
■
 WARNING!
Eliminate Swing Fall
whenever possible! If swing fall exists,
always account for additional fall clearance.
3' / 3.5'
(0,9 / 1,07 m)
Swing Fall
Diagram B - Connections
 


