F L I R . C O M / F X
i
G E T T O K N O W Y O U R
S E C U R I T Y H O M E M O N I T O R I N G
Keep an eye on the things that matter most with
FLIR FX™. Using the mobile app, you can connect
to your camera in Cloud mode via a WiFi network or
through Direct mode with no Internet required. Tap
the camera from the Camera List to view live video
and set up SmartZone motion detection. Manage
push notifications and automatic recording through
the camera settings. See your day in a minute by
creating and viewing Rapid Recaps™.
1
1.
Latch: Lock or unlock camera
2
inside mount. Both latches
3
must be firmly locked to ensure
weatherproof rating of the mount.
2.
Accessory Connector: Connect
the camera all the way for outdoor
installation.
3.
Outdoor Night Vision LEDs: See
further in the dark.
4.
Lens Cover: Keep the lens cover
clean using a slightly damp cloth.
Don't use chemical cleaners as
they may damage the lens cover.
5.
Microphone: Record sound and
4
communicate
6.
Speaker: Communicate via 2-way
intercom.
5
6
7
8
9
7.
Adjustment Ring: Loosen to adjust
9.
Sunshade: Push towards the back of
the horizontal position of the camera.
the camera to remove sunshade.
8.
Vertical Adjustment Screw: Loosen
to adjust the vertical position of the
camera.
10
11
12
10. Twist Adjustment Screw: Loosen to
13. Power Cable: Run the power cable
twist the camera head around the
through the cable notch on the stand
stand.
or through the wall.
11. Temperature Sensor
CAUTION: Make sure the power connector
and power outlets are protected from the
12. Mounting Holes: Mount the camera to
elements when installing.
the wall or ceiling.
F I N D H E L P A T F L I R . C O M / F X
