NO. PART NO.
1 QA-101P01
2 QA-101P02
3 QA-101P03
4 QA-101P04
5 QA-101P05
6 QA-101P06
7 QA-101P07
8 QA-101P08
9 QA-101P09
10 QA-101P10
11 QA-101P11
12 QA-101P12
13 QA-101P13
14 QA-101P14
15 QA-101P15
16 QA-101P16
17 QA-101T17
18 QA-101P18
19 QA-101P19
20 QA-101P20
21 QA-101P21
22 QA-101P22
23 QA-101P23
24 QA-101P24
25 QA-101P25
26 QA-101P26
27 QA-101P27
28 QA-101P28
29 QA-101P29
QA-101
DESCRIPTION
Plug
Spring
O-Ring
Valve Stem
O-Ring
Valve Bushing
Air Inlet Bushing
Exhaust Deflector
Muffler
Throttle Lever
Throttle Lever Pin
Motor Housing
Rear End Ball Bearing
Rear End Plate
Cylinder
Steel Ball
Rotor Blade ( 5 pcs )
Rotor
Rotor Collar
Front End Plate
Front Rotor Ball Bearing
Lock Nut
Housing Cap
Spindle
Collet
Collet Nut
12# Spanner
17# Spanner
Grip
Q'TY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 SET
1
1
1
1
1
1
1
1
1
1
1
1
