Height Right™
WARNING
!
youth chair and is designed for use by children 3 years
of age and up.
WARNING
!
from falls or sliding out.
Parts
Left Side
Right Side
1
e
a
HARDWARE a (3pcs.)
d (3pcs.)
e (3pcs.)
Insert a Wooden Dowel (e) into the larger hole in each of the Back Supports
and Front Support. Insert a Wood Nut (a), as shown into the inner holes of
the 3 Supports. Attach the 3 Wooden Supports as shown and insert Long
Screws (d). Loosely tighten the Long Screws into Wood Nuts through the
Left Side with the Allen Key. Labeling on the Rear Supports should be visible.
3
c
c
Kids Chair
:
The Height Right Kids Chair is a
:
Prevent serious injury or death
Back
Seat
d
Logos this side
a.
d
c
c
d
d
d
2 Back Supports
Front Support
a
Foot Rest (8 pcs.) (4 pcs.) (4 pcs.)
2
FRONT
SUPPORT IS
SHORTER
HARDWARE
Insert a Wood Nut (a), as shown into the inner holes of the Back.
Attach the Back as shown and insert a Long Screw (d). Loosely
tighten the Long Screw into Wood Nut through the Left Side
with the Allen Key.
HARDWARE
a (4pcs.)
d (4pcs.)
e (3pcs.)
Insert the rest of the Dowels, Wood
Nuts, and Screws as needed to
attach the Right Side of the chair.
DO NOT FULLY TIGHTEN SCREWS
WARNING
!
• Always secure child in the restraint
• Never leave child unattended
• Always keep child in view
• Secure straps tightly
• Never use as a stepping stool
• The front edge of the footrest should never
extend beyond the bottom edge of the front
supports at floor level
• Always use chair on a smooth level surface
• SHORTER THAN
BACK SUPPORTS
2 Metal Cross Bars
c d
b
(8 pcs.)
a
d
a (1pcs.)
d (1pcs.)
b.
HARDWARE
c (4pcs.)
Attach the 2 Metal Cross Bars
as shown and insert Screws(c).
Loosely tighten the Screws(c)
into the Metal Cross Bars through
.
Both sides with the Allen Key.
:
Allen Key
e
(6 pcs.) Right + Left Cap
