ASSEMBLY INSTRUCTIONS
4. Attach panel shelves (H) and bottom panel (F) to
the left side frame (A) and right side frame (B) using
M4 x 32mm screws (DD).
Hardware Used
DD M4 x 32mm Screw
5. Attach the metal bar (I) to the left side frame (A) and right
side frame (B) using 1/4" x 10mm bolt (EE) and nut (FF),
tighten with allen wrench (KK) and open wrench (LL).
NOTE: DO NOT fully tighten all bolts until you finish
assembling all parts. Once assembled, go back and fully
tighten all bolts. This will make the assembly easier.
Hardware Used
EE 1/4"x 10mm Bolt
FF Nut
KK
Allen Wrench
LL Open Wrench
6. Insert cam bolts (AA) into drawer front (J). Then,
attach handle (II) to drawer front (J) using 5/32" x
12mm bolts (JJ).
Hardware Used
AA
Cam Bolt
II Handle
JJ
5/32" x 12mm Bolt
4
B
H
x12
DD
5
KK
EE
I
FF
LL
x5
x1
x1
B
x1
6
AA
J
x6
x1
x2
7
ASSEMBLY INSTRUCTIONS
7. Attach drawer left (K) and drawer right (L) to drawer back
(M) using M4 x 32 mm screws (DD).
A
Hardware Used
H
DD M4 x 32mm Screw
F
8. Insert drawer bottom (N) into drawer left (K),
drawer right (L) and drawer back (M).
KK
A
9. Attach drawer front (J) and drawer stretcher (O) to
drawer left (K), drawer right (L) and drawer back (M)
using M4 x 32 mm screws (DD) and small cam locks (HH).
Hardware Used
DD M4 x 32mm Screw
HH Small Cam Lock
II
JJ
7
DD
x4
M
K
8
M
K
9
J
M
L
x2
x6
HH
8
L
L
N
O
K
DD
