STEP-BY-STEP GUIDE
STEP 22
x1 x1 x4
9 18 H
18
Lift the fireplace insert carefully into the back of the assembled mantel and
centre it in the opening. DO NOT drag the insert across the bottom panel as it may
scratch the unit.
9
Using the pilot holes as a guide, fasten the firebox support between the partition
4 5 H
panels and with four M5x12mm pan-head screws .
9
3
H
18
18
