AKRO-MILS 30652 Instructions De Montage

Assembly Instructions
Lean Panel Floor Rack
Model No. 30652, 30654
PARTS:
PARTES:
PIÈCES:
R010496
BOTTOM UPRIGHT
SOPORTE VERTICAL INFERIOR
MONTANT INFÉRIEUR
A x 2
R010497
UNIVERSAL SIDE PANEL
PANEL UNIVERSAL LATERAL
PANNEAU LATÉRAL UNIVERSEL
G x 4
(30654)
x 2
(30652)
TOOLS:
HERRAMIENTAS:
OUTILS :
3/8" & 7/16" SOCKET ON RATCHET
TRINQUETE CON CASQUILLO DE 3/8 Y 7/16 PULG.
DOUILLE DE 3/8 ET 7/16 SUR CLIQUET
SCREWDRIVER
DESTORNILLADOR
TOURNEVIS
3/8 & 7/16 END WRENCH
LLAVE DE EXTREMO ABIERTO DE 3/8 Y 7/16 PULG.
CLÉ PLATE DE 3/8 ET 7/16
All manuals and user guides at all-guides.com
R010500 R011021
TOP UPRIGHT CENTER UPRIGHT
SOPORTE VERTICAL SUPERIOR CONECTOR VERTICAL CENTRAL
MONTANT SUPÉRIEUR MONTANT CENTRAL
B x 2 C x 2
R020567
LEAN PANEL
PANEL INCLINADO
PANNEAU INCLINÉ
H x 12
(30654)
x 6
(30652)
GOGGLES
GAFAS
LUNETTES DE PROTECTION
R010494 R010499
CROSS RAIL UPRIGHT CONNECTOR
RIEL TRANSVERSAL CONECTOR VERTICAL
RAIL TRANSVERSAL CONNECTEUR DE MONTANT
D x 2 E x 3
1/4-20 x 3/4"
HEX HEAD BOLT, WASHER AND NUT
PERNO DE CABEZA HEXAGONAL, ARANDELA Y TUERCA
VIS À TÊTE HEXAGONALE, RONDELLE ET ÉCROU
J x 28
x 20
Akro-Mils prides itself in providing your best value in
storage, organization and material handling products.
If you have any questions, comments or need assistance
with this product please call our toll-free service number:
800-863-5817
Service representatives are available weekdays from 8
a.m. to 5 p.m. Eastern Time to assist you (outside normal
business hours, leave a message and we'll get back to you).
Instrucciones de ensamblaje
Bastidor inclinado
Modelo 30652, 30654
Instructions d'assemblage
Bâti à panneaux inclinés
Modèle 30652, 30654
R010495
BASE
BASE
SOCLE
F x 2
x 1
#14-10 x 3/4"
SLOTTED HEX HEAD WASHER SCREW
TORNILLO DE CABEZA HEXAGONAL RANURADA CON ARANDELA
VIS À TÊTE HEXAGONALE FENDUE À EMBASE
K x 46
(30654)
x 29
(30652)
(30654)
(30652)
(30654)
(30652)
